Paradox Security Systems Toronto: M, EVO & Magellan
Explore Paradox M System, EVO, and Magellan as separate product families so panels, keypads, expansion, wireless, access, communications, and field devices remain in the correct architecture.
- M System, EVO, and Magellan kept as distinct architectures
- Modules and devices considered under their supported family
- Existing published specifications preserved with a source-audit gate
Three Platforms, Clearly Separated
Choose the Paradox family before evaluating modules and devices
The M System, EVO, and Magellan serve different project and service paths. A similar product name or function does not make a module interchangeable across platforms.
MSSCO begins with the panel family, regional model, project capacity, wired and wireless infrastructure, keypads, outputs, communications, monitoring, access requirements, and future service plan. Product-level compatibility is then verified within that architecture.
Platform Paths
Start with the architecture and operating goal
These paths support planning. They are not automatic product or compatibility recommendations.
EVO
Expandable panel, bus, keypad, detector, output, access, and special-module references for suitable projects.
Browse EVO referencesMagellan
Panel and compatible wireless, keypad, communication, detector, siren, and accessory references for the Magellan family.
Browse Magellan referencesPlanning Catalogue
Paradox M, EVO, and Magellan product references
129 records organized by family and category.
Reference status
Existing published reference preserved for staging migration; manufacturer evidence audit remains required before specifications become governed production rules. No record on this page is a price, inventory promise, engineering approval, or automatic compatibility rule.
Product Family
M System
Console
M25 / M25 LTE
The central controller for a modern Paradox installation, combining encrypted M wireless, Ethernet, Wi-Fi and optional LTE in a compact PoE-powered unit.
- Total Zones and Signaling Inputs
- 200
- Partitions
- 10
- Users
- 128; One owner, masters, users, guests, and maintenance
Specifications and planning notes
| Power Supply | PoE (15.4W, 44V – 57V DC) |
|---|---|
| Power Consumption | Max 100mA (standby and alarm) |
| Wireless Type | GFSK with frequency and encryption hopping |
| RF Power | 868 MHz band (+14 dBm), 914 MHz band (+22 dBm), coin battery devices limited to +14 dBm. |
| RF Frequency | 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz; certain countries may have limited or different frequencies. |
| Battery | 3.7V Lithium-ion battery, 5000 mAh |
| Battery Backup Time | 26H on Ethernet, 24H on Wi-Fi, 20H on LTE |
| Operating Temperature | -25°C to 55°C (–13°F to 131°F). Battery charge disabled below 0°C and above +55°C internal temperature |
| Ethernet / Wi-Fi | Built-in Wi-Fi – 2.4 GHz B/G/N |
| LTE | Built-in (LTE Model), main channel, or backup |
| Users | 128; One owner, masters, users, guests, and maintenance |
| BlueEye User Access | Optional, enabled by owner or master per user |
| JPEGs for User and Partition | Yes, from gallery or camera |
| Partitions | 10 |
| Bell Output | Only wireless |
| Total Zones and Signaling Inputs | 200 |
| Remotes | 128 max per system, up to 4 per user |
| Wireless Devices | Maximum Number of Nodes: 75 per system Node Type Limits: K38M maximum of 10 SR230M/SR250M maximum of 10 |
| Adding Devices | Via auto-learn feature (wireless & Ethernet), QR scan, or manual serial number input for pre-programming |
| Wireless Repeaters | Max 4 per system. Ethernet or wireless |
| Programmable Outputs | Up to 48 with wireless expanders; regular, restricted to selected users, or installer-only |
| PGM Activation | Manual, schedule, system events, sunset/sunrise, temperature |
| PGM Status Verification | Zone verification with timer-based error display |
| Ethernet Expansion Devices | Up to 45: repeaters, keypads, cameras, access modules |
| Video Verification | Up to 16 cameras (available soon) |
| Access Control | Up to 16 doors (available soon) |
| Arming Options | Stay, Sleep, and Full Arm |
| Auto Arm | On schedule or no movement For detailed instructions, please refer to the BlueEye User Manual. |
| Auto Disarm | On schedule, Sleep to Stay, Stay to Disarm |
| Humidity Range | 93% maximum (ULC) |
| Security Events | 1,000 |
| Events When the System is Disarmed | 1000 (available soon) |
| Automation Events | 1000 (available soon) |
| Access Events | 7500 (available soon) |
| Installation | By registered installer with Paradox Service Company ID (PCI) from BlueEye or Service Company Portal |
| Service Company Access | Permanent or owner-granted |
| Service Company Lock | Auto-enabled with Swan subscription |
| Service Company Portal | Available to PSCI-registered companies/installers |
| Temperature Display & Control | Site/area display, PGM activation (cool/heat), alerts via push & message center |
| Cloud Services | Paradox Swan 4G (subscription required) |
| Reporting | Up to 4 converters, 2 channels with backup |
| Programming | via Blue Eye app or web base (cloud) software |
| Colors | White |
| Dimensions | 12.4W x 12.4H x 3.55D cm (4.89″ W x 4.89″ H x 1.4″ D) |
| Weight | 0.26 Kg |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewRange Extension
RPT5M Wireless Repeater
Extends M-system radio coverage across larger homes, commercial buildings and detached structures while using Ethernet or Wi-Fi backhaul.
- Battery Backup Time
- 26H on Ethernet, 24H on Wi-Fi
- Battery
- 3.7V Lithium-ion battery, 5000 mAh
- RF Frequency
- 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz — might vary in different countries
Specifications and planning notes
| Power Supply | PoE, 10W max |
|---|---|
| Wireless Type | GFSK two-way with frequency and encryption hopping |
| RF Power | 868 MHz up to +14 dBm radiated, 914 MHz up to +22 dBm in permitted countries |
| RF Frequency | 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz — might vary in different countries |
| Battery | 3.7V Lithium-ion battery, 5000 mAh |
| Battery Backup Time | 26H on Ethernet, 24H on Wi-Fi |
| Operating Temperature | -25°C to +55°C (-13°F to 131°F) Battery charge disabled below 0°C and above +55°C internal temperature |
| Humidity | 93% maximum (ULC) |
| Ethernet/ Wi-Fi | Built-in Wi-Fi – 2.4 GHz B/G/N |
| Remotes | Follow Console |
| Wireless Devices | 75 per system |
| Adding Devices | Via auto-learn feature or manual |
| Installation | By a registered installer with Paradox Company ID (PCI) from BlueEye or Service Company Portal. |
| Programming | via BlueEye application or PC software |
| Colors | White |
| Dimensions | 12.4W x 12.4H x 3.55D cm (4.89″ W x 4.89″ H x 1.4″ D) |
| Weight | 0.26 Kg |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewZone & Output Expansion
ZX10M 10-Zone Expander
Adds ten supervised wired inputs to an M25 design, making it practical to reuse cabling or connect specialized hardwired devices.
- Number of Inputs
- 10
- Battery
- 2 x 3.7V Li-ion battery, 5000 mAh
- RF Frequency
- 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz; may vary by country
Specifications and planning notes
| Power Input | 12-14.0VDC/1A |
|---|---|
| Wireless Type | GFSK two-way with frequency and encryption hopping |
| RF Frequency | 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz; may vary by country |
| RF Power | 868 MHz: +14 dBm radiated, 914 MHz: +22 dBm in permitted countries |
| Number of Inputs | 10 |
| Input Connection Type | Two wires, No EOL, 1EOL A (1 kilo ohm), 1EOL B (1kilo ohm), 2EOL (2 x 1 kilo ohm), Zone one can be set as two-wire smoke |
| Status Indicators in Application | Zone open/close, tamper status, power supply, battery level, temperature, TX/RX values |
| Status Indication | Logo: online, offline, battery or power operation, upgrade in process, tamper, zone LEDs – open/close |
| Battery | 2 x 3.7V Li-ion battery, 5000 mAh |
| Aux Output Supply | 12.5 – 13.8V, rated at 220 mA, (12 hours battery backup at 180 mA), auxiliary maximum 400 mA |
| Transmission Time | Less than 20 ms |
| Supervision Time | 20 minutes, 10 minutes (Default), and 3 minutes |
| Installation Environment | Indoor |
| Operating Temperature | -20°C to 50°C (–4°F to 122°F) |
| Battery Charging | 0°C to 40°C (32°F to 104°F) |
| Humidity Range | 95% maximum |
| Firmware Upgrade | Remotely over the air, via BlueEye |
| Auto Learn | Yes |
| Colors | White |
| Dimensions | 18W x 13H x 4.5D cm (7.09″ W x 5.12″ H x 1.79″ D) |
| Weight | 0.41 kg |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility review
ZP2M Dual I/O Expander
Provides two programmable inputs and two relay outputs for doors, gates, garage controls and other local integration points.
- Number of Inputs
- Two fully programmable zones or signaling inputs
- Number of Outputs
- Two relay outputs 30V / 2A, normally open or close, configurable
- Battery
- 1 x 3.7V Li-ion rechargeable battery, 1000 mAh, 2 hours backup @100 mA aux. (min. 15 mA load required to power Aux)
Specifications and planning notes
| Power Input | 12 VDC / 500 mA Min. (Power Pack or M console aux) |
|---|---|
| Device Input Current | 200 mA Max |
| Power Consumption | 2.4 W Max |
| Bus Connection | M-Bus encrypted RS-485, up to 1,000 ft |
| Battery | 1 x 3.7V Li-ion rechargeable battery, 1000 mAh, 2 hours backup @100 mA aux. (min. 15 mA load required to power Aux) |
| Aux Output Supply | 11V to 13.8V DC, 100 mA |
| Wireless Type | GFSK two-way with frequency and encryption hopping |
| RF Frequency | 868 (865.05–867.95) MHz or 914 (902.25–927.55) MHz; may vary by region |
| RF Power | 868 MHz: +14 dBm radiated; 914 MHz: +22 dBm (permitted countries) |
| Number of Inputs | Two fully programmable zones or signaling inputs |
| Input Connection Type | No EOL, 1EOL or Two EOL (1K ohm) |
| Number of Outputs | Two relay outputs 30V / 2A, normally open or close, configurable |
| In Application Status Indication | Zone open/close, Output open/close, tamper status, power available, battery level, temperature, TX/RX values, wireless or Bus connection |
| Status Indication | Logo: Bus or wireless, online, offline, battery or power operation, upgrade in process, tamper, zone LEDs – open/close, Output Active or not |
| Transmission Time | Less than 20 ms |
| Supervision Time | 20 minutes, 10 minutes (Default), and 3 minutes |
| Installation Environment | Indoor |
| Firmware Upgrade | Remotely via Bus or over-the-air M wireless |
| Operating Temperature | -20°C to 50°C (-4°F to 122°F) |
| Battery Charging Temperature | 0°C to 40°C (32°F to 104°F) |
| Humidity | 93% maximum (ULC) |
| Auto Learn | Yes |
| Colors | White |
| Dimensions | 8.7W x 6.9H x 3D cm (3.4″W x 2.7″H x 1.2″D) |
| Weight | 0.109 kg |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility review
PGM8M 8-Output Expander
Adds eight controllable relay outputs for lights, locks, indicators and equipment that needs event-, schedule- or app-based control.
- Number of Outputs
- 8 Relay Output Rating (per output) – 30V / 2A
- Internal Battery
- 1 × 3.7V Li-ion battery with up to 10 days of battery life — 5000 mAh (optional)
- RF Frequency
- 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz (May vary by country)
Specifications and planning notes
| Power Input | 12–13.8VDC / 1A |
|---|---|
| Wireless Type | GFSK two-way with frequency and encryption hopping |
| RF Frequency | 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz (May vary by country) |
| RF Power | 868 MHz: +14 dBm radiated, 914 MHz: +22 dBm in permitted countries |
| Number of Outputs | 8 Relay Output Rating (per output) – 30V / 2A |
| Status Indicators in Application | Output status indications, tamper status, power supply, battery level, temperature, TX/RX values |
| Status Indication (Logo) | Online, offline, battery or power operation, upgrade in process, tamper Output status indicators: activated/deactivated |
| Internal Battery | 1 × 3.7V Li-ion battery with up to 10 days of battery life — 5000 mAh (optional) |
| Transmission Time | Less than 20ms |
| Supervision Time | 20 minutes, 10 minutes (Default), and 3 minutes |
| Installation Environment | Indoor |
| Firmware Upgrade | Remotely over the air, via BlueEye |
| Operating Temperature | -20°C to 50°C (–4°F to 122°F) |
| Battery Charging Temperature | 0°C to 40°C (32°F to 104°F) |
| Auto Learn | Yes |
| Colors | White |
| Dimensions | 18W x 13H x 4.5D cm (7.09″ W x 5.12″ H x 1.79″ D) |
| Weight | 0.36 Kg with battery |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility review
PGM4M 4-Output Expander
A four-output expansion option for smaller automation tasks that still need monitored wireless communication and manual control.
- Number of Outputs
- 4 Relay Output Rating (per output) – 30V / 2A
- Battery
- 1 × 3.7V Li-ion battery with up to 10 days of battery life — 5000 mAh (optional)
- RF Frequency
- 868 (865.05–867.95) MHz or 914 (902.25–927.55) MHz; may vary by region
Specifications and planning notes
| Power Input | 12–13.8VDC / 1A |
|---|---|
| Wireless Type | GFSK two-way with frequency and encryption hopping |
| RF Frequency | 868 (865.05–867.95) MHz or 914 (902.25–927.55) MHz; may vary by region |
| RF Power | 868 MHz: +14 dBm radiated; 914 MHz: up to +22 dBm in permitted countries |
| Number of Outputs | 4 Relay Output Rating (per output) – 30V / 2A |
| Status Indicators (In Application) | Output status, tamper status, power supply, battery level, temperature, TX/RX values |
| Status Indication (Logo) | Online, offline, battery or power operation, upgrade in process, tamper Output status indicators: activated/deactivated |
| Battery | 1 × 3.7V Li-ion battery with up to 10 days of battery life — 5000 mAh (optional) |
| Transmission Time | Less than 20 ms |
| Supervision Time | 20 minutes, 10 minutes (Default), and 3 minutes |
| Installation Environment | Indoor |
| Firmware Upgrade | Remotely over the air via BlueEye |
| Operating Temperature | -20°C to 50°C (–4°F to 122°F) |
| Battery Charging Temperature | 0°C to 40°C (32°F to 104°F) |
| Auto Learn | Yes |
| Colors | White |
| Dimensions | 18W × 13H × 4.5D cm (7.09″ W × 5.12″ H × 1.79″ D) |
| Weight | 0.36 kg with battery |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility review
PGMZ1M Single-Output Expander
A compact single-relay module with one zone input and temperature sensing for focused control at a remote device or enclosure.
- Number of Outputs, Inputs
- One relay output 24V/1A, One zone input
- RF Frequency
- 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz; may vary by region
- Power Input
- AC/DC 5–16V, 300mA minimum
Specifications and planning notes
| Power Input | AC/DC 5–16V, 300mA minimum |
|---|---|
| Wireless Type | GFSK two-way with frequency and encryption hopping |
| RF Frequency | 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz; may vary by region |
| RF Power | 868 MHz: +14 dBm radiated, 914 MHz: up to +22 dBm in permitted countries |
| Number of Outputs, Inputs | One relay output 24V/1A, One zone input |
| Status Indicators in Application | Output status indications, tamper status, power supply, temperature, TX/RX values |
| Transmission Time | Less than 20ms |
| Supervision Time | 20 minutes, 10 minutes (Default), and 3 minutes |
| Installation Environment | Indoor/Outdoor |
| Firmware Upgrade | Remotely over the air, via BlueEye, about 2 minutes after start delay |
| Operating Temperature | -30°C to 50°C (-22°F to 122°F) |
| Auto Learn | Yes |
| Colors | White |
| Dimensions | 4.6W x 12.45H x 3.3D cm (1.8″ W x 4.9″ H x 1.3″ D) |
| Weight | 77 g |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewKeypads
K70M 7-inch Touchscreen
A full-colour touchscreen for everyday security control, camera viewing and system interaction from a wall-mounted interface.
- Display
- 1024 × 600 color touch display
- Battery
- Built-in rechargeable battery providing up to 6 hours of operation
- Input Power Supply
- 12V DC, minimum 500 mA
Specifications and planning notes
| Input Power Supply | 12V DC, minimum 500 mA |
|---|---|
| Display | 1024 × 600 color touch display |
| Speakers | Internal and External |
| Audio Output Power | 4 W RMS for background music |
| Status Indicators in Application | Power supply, battery level, temperature |
| M System Connectivity | Wi-Fi (2.4 GHz) |
| Battery | Built-in rechargeable battery providing up to 6 hours of operation |
| Installation Environment | Indoor |
| Firmware Upgrade | Through the Swan server (only through Wi-Fi) |
| Operating Temperature | -5°C to 45°C (23°F to 113°F) |
| Auto Learn | Yes |
| Colors | White, Grey |
| Dimensions | 19.50W x 11.28H x 1.74D cm (7.7″ W x 4″ H x 0.7″ D) |
| Weight | 0.46 kg |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility review
K38M Wireless LCD Keypad
A long-life wireless keypad for arming, disarming, panic functions and local status without requiring a new cable run.
- Number of Supported Zones
- 48
- Battery
- 2 x Lithium AA, 6+ years of battery life with normal usage
- RF Frequency
- 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz, might vary in different countries
Specifications and planning notes
| Power Input | 6 to 14 VDC, 100 mA (minimum) |
|---|---|
| Wireless Type | GFSK two-way with frequency and encryption hopping |
| RF Frequency | 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz, might vary in different countries |
| Number of Supported Zones | 48 |
| RF Power | 868 MHz up to +14 dBm radiated, 914 MHz up to +22 dBm in permitted countries |
| Status Indicators in Application | Power supply, battery level, temperature, TX/RX values |
| Battery | 2 x Lithium AA, 6+ years of battery life with normal usage |
| Transmission Time | Less than 20ms |
| Supervision Time | 20 minutes, 10 minutes (Default), and 3 minutes |
| Installation Environment | Indoor |
| Firmware Upgrade | Remotely over the air, via BlueEye, takes approximately 2 minutes to complete after the transfer begins. Battery-powered mode: A delay of up to 2 seconds before the panel starts transferring the firmware. Plugged-in mode: The firmware transfer starts immediately. |
| Operating Temperature | -20°C to 50°C (-4°F to 122°F) |
| Auto Learn | Yes |
| Colors | White |
| Dimensions | 12.3W x 14.4H x 3.2D cm (4.9″ W x 5.7″ H x 1.3″ D) |
| Weight | 0.26 Kg |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewDoor & Window Contacts
DCT12M Door/Window Contact
A supervised magnetic contact with an additional wired input, useful when one wireless point must monitor two related conditions.
- Battery
- ER17335, 10+ years of battery life
- RF Frequency
- 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz; may vary by region
- Operating Temperature
- -30°C to 50°C (–22°F to 122°F)
Specifications and planning notes
| Wireless Type | GFSK two-way with frequency and encryption hopping |
|---|---|
| RF Frequency | 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz; may vary by region |
| RF Power | 868 MHz up to +14 dBm radiated, 914 MHz up to +22 dBm (in permitted countries) |
| Close Distance of the Magnet (L/R) | Less than 1 cm (0.4″) |
| Open Distance of the Magnet (L/R) | Above 2 cm (1.1″) |
| Transmission Time | Less than 20 ms |
| Supervision Time | 20 minutes, 10 minutes (Default), and 3 minutes |
| Input Connection Type | No EOL, 1 EOL A (47kΩ), 1 EOL B (47kΩ), 2 EOL (2 x 47kΩ) |
| Status Indicators | Battery, temperature, TX/RX values |
| Battery | ER17335, 10+ years of battery life |
| Installation Environment | Indoor |
| External Contact Cable Resistance | Up to 50-ohm resistance |
| Firmware Upgrade | Remotely over the air, via BlueEye |
| Operating Temperature | -30°C to 50°C (–22°F to 122°F) |
| Battery Charging Temperature | 0°C to 40°C (32°F to 104°F) |
| Auto Learn | Yes |
| Colors | White, Brown, Grey |
| Dimensions | 3.4W x 9.6H x 2.1D cm (1.3″W x 3.8″H x 0.8″D) |
| Weight | Sensor: 47g / Magnet: 12g |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility review
DCT2M Mini Contact
A small surface-mounted sensor for discreet monitoring of doors and windows, with onboard temperature reporting.
- Battery
- 1 x CR123A, 6+ years of battery life with normal usage
- RF Frequency
- 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz; may vary by region.
- Operating Temperature
- -30°C to 50°C (-22°F to 122°F)
Specifications and planning notes
| Wireless Type | GFSK two-way with frequency and encryption hopping |
|---|---|
| RF Frequency | 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz; may vary by region. |
| RF Power | 868 MHz up to +14 dBm radiated, 914 MHz up to +22 dBm in permitted countries |
| Close Distance of the Magnet | Less than 1 cm (0.4″) |
| Open Distance of the Magnet | Above 3 cm (1.1″) |
| Transmission Time | Less than 20 ms |
| Supervision Time | 20 minutes, 10 minutes (Default), and 3 minutes |
| Status Indicators | Battery, temperature, TX/RX values |
| Battery | 1 x CR123A, 6+ years of battery life with normal usage |
| Installation Environment | Indoor |
| Firmware Upgrade | Remotely over the air, via BlueEye |
| Operating Temperature | -30°C to 50°C (-22°F to 122°F) |
| Auto Learn | Yes |
| Colors | White, Grey, Brown |
| Dimensions | 2W x 9H x 2D cm (¾” W x 3.5″ H x ¾” D) |
| Weight | Sensor 33 g/ Magnet 12g |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility review
DCT6M In-Frame Contact
A slim recessed-style contact designed to sit within a door or window frame for a cleaner finished installation.
- Battery
- 1 x ER10450 lithium only, 6+ years of battery life with normal usage
- RF Frequency
- 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz; may vary by region
- Operating Temperature
- -30°C to 50°C (-22°F to 122°F)
Specifications and planning notes
| Wireless Type | GFSK two-way with frequency and encryption hopping |
|---|---|
| RF Frequency | 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz; may vary by region |
| RF Power | 868 MHz up to +14 dBm radiated, 914 MHz up to +22 dBm in permitted countries |
| Close Distance of the Magnet | 2.0 cm (0.8″) |
| Open Distance of the Magnet | 2.3 cm (0.9″) |
| Transmission Time | Less than 20 ms |
| Supervision Time | 20 minutes |
| Status Indicators | Battery, temperature, TX/RX values |
| Battery | 1 x ER10450 lithium only, 6+ years of battery life with normal usage |
| Installation Environment | Indoor |
| Firmware Upgrade | Remotely over the air, via BlueEye |
| Operating Temperature | -30°C to 50°C (-22°F to 122°F) |
| Auto Learn | Yes |
| Colors | White |
| Dimensions | 2.1W x 7.3H x 2.1D cm (0.8″ W x 2.8″ H x 0.8″ D) |
| Weight | Sensor 20 g, Magnet 10 g |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewMotion & Life-Safety Detectors
PMD5M Mini Motion Detector
A compact indoor detector for rooms where reliable motion coverage is needed without a visually dominant sensor.
- Battery
- 1 x CR123 lithium, 6+ years of battery life with normal usage
- RF Frequency
- 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz — May vary by region
- Operating Temperature
- -20°C to 40°C (-4°F to 104°F)
Specifications and planning notes
| Wireless Type | GFSK two-way with frequency and encryption hopping |
|---|---|
| Sensor Type | Dual rectangular element |
| Coverage | 110° – 12m (39 ft) x 12m (39 ft) |
| Detection Speed | 0.2m/s to 3.5m/s (0.6 ft/s to 11.5 ft/s) |
| RF Frequency | 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz — May vary by region |
| RF Power | 868 MHz up to +14 dBm radiated, 914 MHz up to +22 dBm in permitted countries |
| Transmission Time | Less than 20 ms |
| Supervision Time | 20 minutes, 10 minutes (Default), and 3 minutes |
| Status Indicators | Battery, temperature, TX/RX values |
| Battery | 1 x CR123 lithium, 6+ years of battery life with normal usage |
| Firmware Upgrade | Remotely over the air, via BlueEye |
| Installation Environment | Indoor |
| Operating Temperature | -20°C to 40°C (-4°F to 104°F) |
| Auto Learn | Yes |
| Colors | White, Grey |
| Dimensions | 5.6W x 9.2H x 1.8D cm (2.2″ W x 3.6″ H x 0.7″ D) |
| Weight | 80 g |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility review
PMD3M Single-Optic PIR
A straightforward indoor passive-infrared detector for general residential and light-commercial protection.
- Battery
- 2 x AA lithium, 6+ years of battery life with normal usage
- RF Frequency
- 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz; may vary by region
- Operating Temperature
- -20°C to 40°C (-4°F to 104°F)
Specifications and planning notes
| Wireless Type | GFSK two-way with frequency and encryption hopping |
|---|---|
| Sensor Type | Dual rectangular element |
| Coverage | 110° – 12m (39 ft) x 12m (39 ft) |
| Detection Speed | 0.2m/s to 3.5m/s (0.6 ft/s to 11.5 ft/s) |
| RF Frequency | 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz; may vary by region |
| RF Power | 868 MHz up to +14 dBm radiated, 914 MHz up to +22 dBm in permitted countries |
| Transmission Time | Less than 20ms |
| Supervision Time | 20 minutes, 10 minutes (Default), and 3 minutes |
| Status Indicators | Battery, temperature, TX/RX values |
| Battery | 2 x AA lithium, 6+ years of battery life with normal usage |
| Installation Environment | Indoor |
| Firmware Upgrade | Remotely over the air, via BlueEye |
| Auto Learn | Yes |
| Operating Temperature | -20°C to 40°C (-4°F to 104°F) |
| Colors | White |
| Dimensions | 6.6W x 9.9H x 6.1D cm (2.6″ W x 3.9″ H x 2.4″ D) |
| Weight | 0.13 Kg |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility review
PMD75M Pet-Immune Detector
Uses dual optics and digital processing to improve motion decisions in spaces shared with household pets.
- Battery
- 3 x AAA Lithium, 6+ years of battery life with normal usage
- RF Frequency
- 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz, May vary by region
- Operating Temperature
- -20°C to 40°C (-4°F to 104°F)
Specifications and planning notes
| Wireless Type | GFSK two-way with frequency and encryption hopping |
|---|---|
| Sensor Type | Two dual-opposed infrared sensors |
| Coverage | 90° – 11m (36 ft) x 11m (36 ft); Center beams: 15m (49.2 ft) |
| Detection Speed | 0.2m/s to 3.5m/s (0.6 ft/s to 11.5 ft/s) |
| RF Frequency | 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz, May vary by region |
| RF Power | 868 MHz up to +14 dBm radiated, 914 MHz up to +22 dBm in permitted countries |
| Transmission Time | Less than 20 ms |
| Supervision Time | 20 minutes, 10 minutes (Default), and 3 minutes |
| Status Indicators | Battery, temperature, TX/RX values |
| Battery | 3 x AAA Lithium, 6+ years of battery life with normal usage |
| Installation Environment | Indoor |
| Firmware Upgrade | Remotely over the air, via BlueEye |
| Operating Temperature | -20°C to 40°C (-4°F to 104°F) |
| Auto Learn | Yes |
| Colors | White |
| Dimensions | 6.6W x 12.4H x 6.1D cm (2.6″ W x 4.9″ H x 2.4″ D) |
| Weight | 0.16 Kg |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility review
PMD37M Curtain Detector
Creates a narrow protective curtain for windows, doors, balconies or perimeter approaches and includes anti-mask supervision.
- Detection Range
- PET Immunity mode: 7.5m x 2m (25 x 7 ft)
- Battery
- 2 x AA lithium, 6+ years of battery life with normal usage
- RF Frequency
- 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz; May vary by region
Specifications and planning notes
| Wireless Type | GFSK two-way with frequency and encryption hopping |
|---|---|
| Sensor Type | 2 dual elements |
| Coverage | 88.5° – 11m (36 ft) x 11m (36 ft); Center beams: 15m (49.2 ft) |
| Detection Range | PET Immunity mode: 7.5m x 2m (25 x 7 ft) |
| RF Frequency | 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz; May vary by region |
| RF Power | 868 MHz up to +14 dBm radiated, 914 MHz up to +22 dBm in permitted countries |
| Transmission Time | Less than 20ms |
| Supervision Time | 20 minutes, 10 minutes (Default), and 3 minutes |
| Status Indicators | Battery, temperature, TX/RX values |
| Battery | 2 x AA lithium, 6+ years of battery life with normal usage |
| Installation Environment | Outdoor |
| Firmware Upgrade | Remotely over the air, via BlueEye |
| Operating Temperature | -20°C to 40°C (-4°F to 104°F) |
| Auto Learn | Yes |
| Colors | White |
| Dimensions | 6.1W x 12.3H x 4.3D cm (2.4″ W x 4.8″ H x 1.7″ D) |
| Weight | 0.17 Kg |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility review
PMD85M Outdoor Detector
Weather-ready motion protection for exterior approaches, with pet-tolerant detection logic for carefully planned outdoor zones.
- Battery
- 3 x AA lithium, 6 + years of battery life with normal usage
- RF Frequency
- 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz; May vary by region
- Operating Temperature
- -20°C to 40°C (-4°F to 104°F)
Specifications and planning notes
| Wireless Type | GFSK two-way with frequency and encryption hopping |
|---|---|
| Sensor Type | Dual element infrared (x2) |
| Coverage | 90° – 11m (36 ft) x 11m (36 ft) |
| Detection Speed | 0.2 m to 3.5 m/s (0.6 ft to 11.5 ft/s) |
| RF Frequency | 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz; May vary by region |
| RF Power | 868 MHz up to +14 dBm radiated, 914 MHz up to +22 dBm in permitted countries |
| Transmission Time | Less than 20ms |
| Supervision Time | 20 minutes, 10 minutes (Default), and 3 minutes |
| Status Indicators | Battery, temperature, TX/RX values |
| Battery | 3 x AA lithium, 6 + years of battery life with normal usage |
| Installation Environment | Indoor/Outdoor |
| Firmware Upgrade | Remotely over the air, via BlueEye |
| Operating Temperature | -20°C to 40°C (-4°F to 104°F) |
| Auto Learn | Yes |
| Colors | White |
| Dimensions | 8.3W x 17.5H x 7.4D cm (3.29″ W x 6.9″ H x 2.9″ D) |
| Weight | 0.27 kg |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility review
PMD780M Dual-Side Outdoor Detector
Protects two opposing outdoor directions from one mounting point, helping cover façades, side passages and boundary lines.
- Battery
- 3 x AA lithium, 6+ years of battery life with normal usage
- RF Frequency
- 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz; May vary by region
- Operating Temperature
- -20°C to 40°C (-4°F to 104°F)
Specifications and planning notes
| Wireless Type | GFSK two-way with frequency and encryption hopping |
|---|---|
| Sensor Type | 4 x dual low-noise rectangular elements |
| Coverage | 3m (9.8ft) – 12m (39.37ft) on each side at 1.5m / 4.9 ft. height |
| Detection Speed | 0.2m/sec. – 4m/sec. (0.6 ft/sec. – 13.1 ft/sec.) |
| RF Frequency | 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz; May vary by region |
| RF Power | 868 MHz up to +14 dBm radiated, 914 MHz up to +22 dBm in permitted countries |
| Humidity Range | 95% max. |
| Transmission Time | Less than 20ms |
| Supervision Time | 20 minutes, 10 minutes (Default), and 3 minutes |
| Status Indicators | Battery, temperature, TX/RX values |
| Battery | 3 x AA lithium, 6+ years of battery life with normal usage |
| Installation Environment | Outdoor |
| Firmware Upgrade | Remotely over the air, via BlueEye |
| Operating Temperature | -20°C to 40°C (-4°F to 104°F) |
| Auto Learn | Yes |
| Colors | White |
| Dimensions | 11W x 21H x 7D cm (4.3″ W x 8.2″ H x 2.7″ D) |
| Weight | 0.45 Kg |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility review
AMD12M Motion Sensor
A versatile M-series motion sensor for supervised indoor detection and rapid encrypted event transmission.
- Battery
- 1 x CR2032 lithium, 3+ years of battery life with normal usage
- RF Frequency
- 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz, May vary by region
- Operating Temperature
- -20°C to 50°C (32°F to 122°F)
Specifications and planning notes
| Wireless Type | GFSK two-way with frequency and encryption hopping |
|---|---|
| Sensor Type | Three-axis accelerometer |
| RF Frequency | 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz, May vary by region |
| RF Power | 868 MHz up to +14 dBm radiated, 914 MHz up to +14 dBm maximum, power managed |
| Transmission Time | Less than 20 ms |
| Supervision Time | 20 minutes |
| Status Indicators | Battery, temperature, TX/RX values |
| Battery | 1 x CR2032 lithium, 3+ years of battery life with normal usage |
| Firmware Upgrade | Remotely over the air, via BlueEye |
| Installation Environment | Indoor |
| Operating Temperature | -20°C to 50°C (32°F to 122°F) |
| Auto Learn | Yes |
| Colors | White / Black |
| Dimensions | 3W x 7.6H x 1D cm (1.2″ W x 3″ H x 0.4″ D) |
| Weight | 20 grams |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility review
SD760M10 Smoke Detector
A ten-year smoke detector that adds supervised life-safety notification to a professionally designed M25 system.
- Battery
- 1 x CR123 lithium, 10 years of battery life with normal usage
- RF Frequency
- 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz, May vary by region
- Operating Temperature
- 4.4°C to 37.8°C (40°F to 100°F)
Specifications and planning notes
| Wireless Type | GFSK two-way with frequency and encryption hopping |
|---|---|
| RF Frequency | 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz, May vary by region |
| RF Power | 868 MHz up to +14 dBm radiated, 914 MHz up to +22 dBm in permitted countries |
| Transmission Time | Less than 20 ms |
| Supervision Time | 20 minutes, 10 minutes (Default), and 3 minutes |
| Status Indicators | Battery, temperature, TX/RX values |
| Battery | 1 x CR123 lithium, 10 years of battery life with normal usage |
| Installation Environment | Indoor |
| Firmware Upgrade | Remotely over the air, via BlueEye |
| Operating Temperature | 4.4°C to 37.8°C (40°F to 100°F) |
| Auto Learn | Yes |
| Colors | White |
| Dimensions | 12 Ø x 4.6 cm (4.8″ Ø x 1.9″) |
| Weight | 0.21 Kg |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewRemote Controls
REM101M Panic/Call Remote
A simple wireless call button for users who need a fast, clearly defined panic or assistance action.
- Battery
- 1 x CR2354 lithium
- RF Frequency
- 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz
- Operating Temperature
- -20°C to +50°C (–4°F to 122°F)
Specifications and planning notes
| Wireless Type | GFSK two-way with encryption hopping |
|---|---|
| RF Frequency | 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz |
| RF Power | 868 MHz up to +14 dBm, 914 MHz up to +14 dBm |
| Transmission Time | Less than 20 ms to console |
| Battery | 1 x CR2354 lithium |
| Operating Temperature | -20°C to +50°C (–4°F to 122°F) |
| Body Colors | Black, White, Grey |
| Button Colors | Red, Orange, Blue, Green, White, Black, Grey |
| Dimensions (H × W × D) | 6.2H × 3.7W × 1.8D cm (2.4″ H × 1.4″ W × 0.7″ D) |
| Weight | 25 g |
| Certification | CE, FCC 15.247 |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility review
REM28M 8-Function Remote
An eight-function handheld remote for users who need several security and programmable-control actions at hand.
- Battery Lithium
- 1 x CR2032 lithium
- RF Frequency
- 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz range, May vary by region
- Dimensions
- 3.3W x 7.4H x 1.4D cm (1.2″ W x 2.9″ H x 0.55″ D)
Specifications and planning notes
| Wireless Type | GFSK two-way with frequency and encryption hopping |
|---|---|
| RF Frequency | 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz range, May vary by region |
| RF Power | 868 MHz up to +14 dBm radiated, 914 MHz up to +14 dBm |
| Transmission Time | Less than 20 ms |
| Battery Lithium | 1 x CR2032 lithium |
| Colors | White, Black |
| Dimensions | 3.3W x 7.4H x 1.4D cm (1.2″ W x 2.9″ H x 0.55″ D) |
| Weight | 30 g |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility review
REM25M 5-Function Remote
A compact five-function remote for common arming, disarming, panic and programmable actions.
- Battery
- 1 x CR2032 lithium
- RF Frequency
- 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz range, May vary by region
- Operating Temperature
- -20°C to 50°C (-4°F to 122°F)
Specifications and planning notes
| Wireless Type | GFSK two-way with frequency and encryption hopping |
|---|---|
| RF Frequency | 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz range, May vary by region |
| RF Power | 868 MHz up to +14 dBm, 914 MHz up to +14 dBm |
| Transmission Time | Less than 20 ms |
| Battery | 1 x CR2032 lithium |
| Operating Temperature | -20°C to 50°C (-4°F to 122°F) |
| Colors | White, Black |
| Dimensions | 3.9W x 7.2H x 1.2D cm (1.5″ W x 2.8″ H x 0.5″ D) |
| Weight | 30 g |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility review
REM2M 5-Function Remote
A five-button M-series remote that provides convenient two-way system control for everyday users.
- Battery
- 1 x CR2032 lithium
- RF Frequency
- 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz range, May vary by region
- Operating Temperature
- -20°C to 50°C (-4°F to 122°F)
Specifications and planning notes
| Wireless Type | GFSK two-way with frequency and encryption hopping |
|---|---|
| RF Frequency | 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz range, May vary by region |
| RF Power | 868 MHz up to +14 dBm radiated, 914 MHz up to +14 dBm |
| Transmission Time | Less than 20 ms |
| Battery | 1 x CR2032 lithium |
| Operating Temperature | -20°C to 50°C (-4°F to 122°F) |
| Colors | White, Black |
| Dimensions | 3.8W x 7.8H x 1.8D cm (1.5″ W x 3.1″ H x 0.7″ D) |
| Weight | 20 g |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewSirens & Audible Alerts
CM1M Chime & Sound Player
Adds configurable audible feedback, announcements and chime functions to entrances and occupied areas.
- RF Frequency
- 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz, May vary by region
- Operating Temperature
- -30°C to 70°C (-22°F to +158°F)
- Dimensions
- 8.4W x 8.4H x 4.8D cm (3.3″ W x 3.3″ H x 1.9″ D)
Specifications and planning notes
| Wireless Type | GFSK two-way with frequency and encryption hopping |
|---|---|
| RF Frequency | 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz, May vary by region |
| RF Power | 868 MHz up to +14 dBm radiated, 914 MHz up to +22 dBm in permitted countries |
| Number of Ringtones | Zone chime alarm tones: 6 Burglary alarm tones: 8 Fire alarm tones: 8 (same melodies as burglary alarm tones) Entry tone: 1 Exit tone: 1 (same as entry tone) Panic alarm tone: 8 (same melodies as burglary alarm tones) |
| Supervision Time | 20 minutes, 10 minutes, and 3 minutes |
| Installation Environment | Indoor |
| Firmware Upgrade | Remotely over the air, via BlueEye |
| Input Voltage | AC110 ~260V, 50/60Hz |
| Operating Temperature | -30°C to 70°C (-22°F to +158°F) |
| Colors | White |
| Dimensions | 8.4W x 8.4H x 4.8D cm (3.3″ W x 3.3″ H x 1.9″ D) |
| Weight | 82 g |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility review
SR230M Outdoor Siren
A supervised exterior siren that provides a strong local alarm response without requiring a signal cable to the mounting point.
- Battery Alkaline
- 3 x C alkaline, up to 5 years of battery life (due to the risk of leakage from alkaline batteries)
- RF Frequency
- 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz, May vary by region
- Operating Temperature
- -20°C to 50°C (-4°F to 122°F)
Specifications and planning notes
| Current Consumption | Standby: 5.75 μA, Maximum: 450 mA |
|---|---|
| Wireless Type | GFSK two-way with frequency and encryption hopping |
| RF Frequency | 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz, May vary by region |
| RF Power | 868 MHz up to +14 dBm radiated, 914 MHz up to +22 dBm in permitted countries |
| Status Indicators | Battery, temperature, TX/RX values |
| Battery Alkaline | 3 x C alkaline, up to 5 years of battery life (due to the risk of leakage from alkaline batteries) |
| Siren | 100 dBA or more (1 meter), Piezo siren |
| Transmission Time | Less than 20ms |
| Supervision Time | 20 minutes, 10 minutes (Default), and 3 minutes |
| Installation Environment | Outdoor |
| Firmware Upgrade | Remotely over the air, via BlueEye |
| Operating Temperature | -20°C to 50°C (-4°F to 122°F) |
| Auto Learn | Yes |
| Colors | White |
| Dimensions | 13.4W x 21.2H x 5.1D cm (5.3″ W x 8.3″ H x 2″ D) |
| Weight | 0.55 Kg |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility review
SR250M Outdoor Siren
An enhanced outdoor sounder for installations that need wireless supervision, visible status and a durable exterior alert device.
- Battery
- 3 x D alkaline, up to 5 years of battery life (due to the risk of leakage from alkaline batteries)
- RF Frequency
- 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz, May vary by region
- Power Supply Input
- 8-16 Vac / 9-20 Vdc
Specifications and planning notes
| Power Supply Input | 8-16 Vac / 9-20 Vdc |
|---|---|
| Current Consumption | Sleep: 22 uA, Standby: 130 uA, Alarm: 550 mA |
| Wireless Type | GFSK two-way with frequency and encryption hopping |
| RF Frequency | 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz, May vary by region |
| RF Power | 868 MHz up to +14 dBm radiated, 914 MHz up to +22 dBm in permitted countries |
| Status Indicators | Battery, temperature, TX/RX values |
| Battery | 3 x D alkaline, up to 5 years of battery life (due to the risk of leakage from alkaline batteries) |
| Siren | 100 dBA or more (1 meter), Piezo siren |
| Transmission Time | Less than 20ms |
| Supervision Time | 20 minutes, 10 minutes (Default), and 3 minutes |
| Firmware Upgrade | Remotely over the air, via BlueEye |
| Operating Temperature | -20°C to 50°C (-4°F to 122°F) |
| Installation Environment | Outdoor |
| Auto Learn | Yes |
| Colors | White |
| Dimensions | 6W x 24H x 18D cm (2.3″ W x 9.5″ H x 7″ D) |
| Weight | 1.21 Kg |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewWater Protection
WD2M Water Detector
Detects water at floor level and reports the condition to the M system so users can receive alerts or trigger a shutoff response.
- Battery
- 1 ER17335 lithium battery, 10+ years of battery life before replacement
- RF Frequency
- 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz, May vary by region
- Operating Temperature
- -30°C to 50°C (-22°F to 122°F)
Specifications and planning notes
| Detection | Water, Oil |
|---|---|
| Wireless Type | GFSK two-way with frequency and encryption hopping |
| RF Frequency | 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz, May vary by region |
| RF Power | 868 MHz up to +14 dBm radiated, 914 MHz up to +22 dBm in permitted countries |
| Transmission Time | Less than 20 ms |
| Supervision Time | 20 minutes, 10 minutes (Default), and 3 minutes |
| Status Indicators | Battery, temperature, TX/RX values, open, close |
| Battery | 1 ER17335 lithium battery, 10+ years of battery life before replacement |
| Installation Environment | Indoor |
| Firmware Upgrade | Remotely over the air, via BlueEye |
| Operating Temperature | -30°C to 50°C (-22°F to 122°F) |
| IP Rating | IP67 |
| Auto Learn | Yes |
| Colors | Grey, White |
| Dimensions | 6.5W x 5.3H x 2.2D cm (2.6″ W x 2″ H x 0.9″ D) |
| Weight | 77 g |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility review
FD25M Flood Detector
A dedicated flood sensor for mechanical rooms, laundry areas, kitchens and other locations where early leak warning matters.
- Battery
- 1 x CR123 lithium, 6+ years of battery life with normal usage
- RF Frequency
- 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz
- Operating Temperature
- -30°C to 50°C (-22°F to 122°F), Works below 4°C as long as the liquid is not frozen (Detection functions only when the liquid is above its freezing point)
Specifications and planning notes
| Wireless Type | GFSK two-way with frequency and encryption hopping |
|---|---|
| RF Frequency | 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz |
| RF Power | 868 MHz up to +14 dBm radiated, 914 MHz up to +22 dBm in permitted countries |
| Transmission Time | Less than 20ms |
| Supervision Time | 20 minutes, 10 minutes (Default), and 3 minutes |
| Status Indicators | Battery , temperature, TX/RX values |
| Battery | 1 x CR123 lithium, 6+ years of battery life with normal usage |
| Installation Environment | Indoor |
| Firmware Upgrade | Remotely over the air, via BlueEye |
| Operating Temperature | -30°C to 50°C (-22°F to 122°F), Works below 4°C as long as the liquid is not frozen (Detection functions only when the liquid is above its freezing point) |
| Auto Learn | Yes |
| Colors | White |
| Dimensions | 8.9W x8.4H x 2.3D cm (3.5″ W x 3.3″ H x 0.9″ D) |
| Weight | 70 g with bracket |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility review
WV2M Electronic Water Valve
A wireless motorized shutoff valve that can turn leak detection into an active water-damage prevention response.
- Battery
- 2 x ER17335, 6+ years of battery life
- RF Frequency
- 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz, May vary by region
- Operating Temperature
- -20°C to +45°C
Specifications and planning notes
| Wireless Type | GFSK two-way with frequency and encryption hopping |
|---|---|
| RF Frequency | 868 (865.05 – 867.95) MHz or 914 (902.25 – 927.55) MHz, May vary by region |
| RF Power | 868 MHz up to +14 dBm radiated, 914 MHz up to +22 dBm in permitted countries |
| Status Indicators in Application | Battery, temperature, TX/RX values, open/close |
| Opening or Closing Time | Valve mechanical operation – approximately 6 seconds Valve LED status update – approximately 12 seconds Status update in the app – 14 seconds (Depends on communication speed between panel and server) |
| Battery | 2 x ER17335, 6+ years of battery life |
| Humidity Range | Up to 95% |
| Transmission Time | Less than 20 ms |
| Supervision Time | 20 minutes, 10 minutes (Default), and 3 minutes |
| Installation Environment | Indoor/Outdoor |
| Firmware Upgrade | Remotely over the air, via BlueEye |
| Operating Temperature | -20°C to +45°C |
| IP Rating | IP65 for wireless control unit, IP67 for valve |
| Auto Learn | Yes |
| Colors | Black |
| Dimensions | 7.7W x 11.2H x 9D cm (3″ W x 4.4″ H x 3.5″ D) |
| Weight | WV2M (1″) = 0.673 kg WV2M (1/2″) = 0.455 kg WV2M (3/4″) = 0.543 kg |
| Certification | CE, FCC 15.247 |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewPower & Network Accessories
PA12V/1A Power Adapter
A regulated 12-volt, 1-amp power source for compatible M-system devices and installation accessories.
- Input
- 100–240V AC
- Output
- 12V DC / 1A
- Use
- Compatible Paradox M-system accessories
Specifications and planning notes
| Input | 100–240V AC |
|---|---|
| Output | 12V DC / 1A |
| Use | Compatible Paradox M-system accessories |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility review
EG30 PoE+ Injector
Supplies gigabit data and up to 30 watts of PoE+ power over one network cable for compatible M-system equipment.
- Input
- 100–240V AC
- Network
- Gigabit Ethernet
- PoE output
- Up to 30W PoE+
Specifications and planning notes
| Input | 100–240V AC |
|---|---|
| Network | Gigabit Ethernet |
| PoE output | Up to 30W PoE+ |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewMonitoring Receivers
VIPC20 CMS Converter
A Linux-based IP reporting converter for high-capacity monitoring environments that need MQTT security and standard CMS formats.
- Account Capacity
- 20,000 for normal or long supervision, 10,000 for high supervision
- Compatibility
- M head units, legacy panels manufactured after 2012 using IP180, PCS265V8 (LTE), IP150+MQ, IP150 MQTT FW 6.0 or higher
- Supervision
- Long: 20 min, 10 min; Default: 5 min; Short: 90 sec
Specifications and planning notes
| Compatibility | M head units, legacy panels manufactured after 2012 using IP180, PCS265V8 (LTE), IP150+MQ, IP150 MQTT FW 6.0 or higher |
|---|---|
| Account Capacity | 20,000 for normal or long supervision, 10,000 for high supervision |
| Supervision | Long: 20 min, 10 min; Default: 5 min; Short: 90 sec |
| Supervision Message | Account offline/online status reported to CMS |
| Replacement Recovery Time | Auto recovery of VIPC20 within five minutes — all accounts restored |
| Encryption Type | AES 128-bit |
| Communication Protocol | CID via Sur-Gard MLR2-DG or Ademco |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility review
IPC10 Central IP Receiver
A rack-mount IP monitoring receiver built for supervised account reporting, rapid replacement recovery and PoE deployment.
- Power Input
- 12.5W
- Operating Temperature
- 0 to 40 °C (32 to 104 °F)
- Dimensions
- Fits 19” Rack 1U – 48.26 x 20.3 x 4.2 cm (19” x 8” x 1.65” in)
Specifications and planning notes
| Compatibility | IP180 (Ethernet + Wi-Fi), PCS265V8 (LTE), IP150+ FW 6.0 or higher, and Paradox panels with IP or cellular on-board |
|---|---|
| Input Voltage | POE, 37–57 V DC, Class 2 device |
| Power Input | 12.5W |
| Operating Temperature | 0 to 40 °C (32 to 104 °F) |
| Replacement Recovery | Auto recovery in case of replacement for all accounts within 5 minutes |
| Encryption Type | AES 128-bit |
| Communication Protocol | CID via Sur-Gard MLR2-DG or Ademco 685 |
| Dimensions | Fits 19” Rack 1U – 48.26 x 20.3 x 4.2 cm (19” x 8” x 1.65” in) |
| Weight | 3.41 Kg |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewService Portal
Paradox Company Service Portal
The installer-facing workspace for site administration, team access and ongoing service management.
- Primary users
- Authorized Paradox service companies and installers
- Site tools
- View and administer enrolled sites
- Team access
- Invite, grant or revoke installer access
Specifications and planning notes
| Primary users | Authorized Paradox service companies and installers |
|---|---|
| Site tools | View and administer enrolled sites |
| Team access | Invite, grant or revoke installer access |
| Billing tools | Supports batch payments |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewMobile Application
BlueEye Mobile App
The current M-system mobile experience for alerts, user permissions and day-to-day security control from supported phones.
- Platforms
- iOS and Android
- User controls
- Arm, disarm and manage permitted actions
- Notifications
- Real-time security alerts
Specifications and planning notes
| Platforms | iOS and Android |
|---|---|
| User controls | Arm, disarm and manage permitted actions |
| Notifications | Real-time security alerts |
| Access model | Multiple users with individual permissions |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewProduct Family
EVO
Control Panels
EVOHD+
The EVOHD+ is a 192-zone high-security control panel used for central control, partitioning and high-capacity expansion. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- 192-zone high-security control panel
- Family
- Paradox EVO
- Connection
- EVO 4-wire digital bus and model-specific communication modules
Specifications and planning notes
| Model | EVOHD+ |
|---|---|
| Product type | 192-zone high-security control panel |
| Product family | Paradox EVO |
| Category | Control Panels |
| Typical application | central control, partitioning and high-capacity expansion |
| Connection profile | EVO 4-wire digital bus and model-specific communication modules |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewEVO192
The EVO192 is a 192-zone control panel used for central control, partitioning and high-capacity expansion. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- 192-Zone Control Panel
- Family
- Paradox EVO
- Connection
- EVO 4-wire digital bus and model-specific communication modules
Specifications and planning notes
| Model | EVO192 |
|---|---|
| Product type | 192-Zone Control Panel |
| Product family | Paradox EVO |
| Category | Control Panels |
| Typical application | central control, partitioning and high-capacity expansion |
| Connection profile | EVO 4-wire digital bus and model-specific communication modules |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewPGM Expansion Modules
PGM82
The PGM82 is a 8-pgm expansion module used for adding programmable relay and solid-state outputs. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- 8-PGM Expansion Module
- Family
- Paradox EVO
- Connection
- EVO bus-connected expansion
Specifications and planning notes
| Model | PGM82 |
|---|---|
| Product type | 8-PGM Expansion Module |
| Product family | Paradox EVO |
| Category | PGM Expansion Modules |
| Typical application | adding programmable relay and solid-state outputs |
| Connection profile | EVO bus-connected expansion |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewPGM4
The PGM4 is a 4-pgm expansion module used for adding programmable relay and solid-state outputs. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- 4-PGM Expansion Module
- Family
- Paradox EVO
- Connection
- EVO bus-connected expansion
Specifications and planning notes
| Model | PGM4 |
|---|---|
| Product type | 4-PGM Expansion Module |
| Product family | Paradox EVO |
| Category | PGM Expansion Modules |
| Typical application | adding programmable relay and solid-state outputs |
| Connection profile | EVO bus-connected expansion |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewKeypads
TM70 Touch
The TM70 Touch is a intuitive touchscreen used for arming, status, user interaction and local control. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- Intuitive Touchscreen
- Family
- Paradox EVO
- Connection
- EVO bus or model-specific mounting accessory
Specifications and planning notes
| Model | TM70 Touch |
|---|---|
| Product type | Intuitive Touchscreen |
| Product family | Paradox EVO |
| Category | Keypads |
| Typical application | arming, status, user interaction and local control |
| Connection profile | EVO bus or model-specific mounting accessory |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewTM70WB
The TM70WB is a tm70 in-wall bracket used for arming, status, user interaction and local control. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- TM70 In-Wall Bracket
- Family
- Paradox EVO
- Connection
- EVO bus or model-specific mounting accessory
Specifications and planning notes
| Model | TM70WB |
|---|---|
| Product type | TM70 In-Wall Bracket |
| Product family | Paradox EVO |
| Category | Keypads |
| Typical application | arming, status, user interaction and local control |
| Connection profile | EVO bus or model-specific mounting accessory |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewTM50 Touch
The TM50 Touch is a intuitive touchscreen used for arming, status, user interaction and local control. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- Intuitive Touchscreen
- Family
- Paradox EVO
- Connection
- EVO bus or model-specific mounting accessory
Specifications and planning notes
| Model | TM50 Touch |
|---|---|
| Product type | Intuitive Touchscreen |
| Product family | Paradox EVO |
| Category | Keypads |
| Typical application | arming, status, user interaction and local control |
| Connection profile | EVO bus or model-specific mounting accessory |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewTM50WB
The TM50WB is a tm50 in-wall bracket used for arming, status, user interaction and local control. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- TM50 In-Wall Bracket
- Family
- Paradox EVO
- Connection
- EVO bus or model-specific mounting accessory
Specifications and planning notes
| Model | TM50WB |
|---|---|
| Product type | TM50 In-Wall Bracket |
| Product family | Paradox EVO |
| Category | Keypads |
| Typical application | arming, status, user interaction and local control |
| Connection profile | EVO bus or model-specific mounting accessory |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewK641+
The K641+ is a 32-character blue lcd keypad module used for arming, status, user interaction and local control. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- 32-Character Blue LCD Keypad Module
- Family
- Paradox EVO
- Connection
- EVO bus or model-specific mounting accessory
Specifications and planning notes
| Model | K641+ |
|---|---|
| Product type | 32-Character Blue LCD Keypad Module |
| Product family | Paradox EVO |
| Category | Keypads |
| Typical application | arming, status, user interaction and local control |
| Connection profile | EVO bus or model-specific mounting accessory |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewK656
The K656 is a touch sense keypad used for arming, status, user interaction and local control. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- Touch Sense Keypad
- Family
- Paradox EVO
- Connection
- EVO bus or model-specific mounting accessory
Specifications and planning notes
| Model | K656 |
|---|---|
| Product type | Touch Sense Keypad |
| Product family | Paradox EVO |
| Category | Keypads |
| Typical application | arming, status, user interaction and local control |
| Connection profile | EVO bus or model-specific mounting accessory |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewK641R
The K641R is a 32-character blue lcd keypad module with integrated card reader used for arming, status, user interaction and local control. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- 32-Character Blue LCD Keypad Module with Integrated Card Reader
- Family
- Paradox EVO
- Connection
- EVO bus or model-specific mounting accessory
Specifications and planning notes
| Model | K641R |
|---|---|
| Product type | 32-Character Blue LCD Keypad Module with Integrated Card Reader |
| Product family | Paradox EVO |
| Category | Keypads |
| Typical application | arming, status, user interaction and local control |
| Connection profile | EVO bus or model-specific mounting accessory |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewMotion Detectors
NV780MX
The NV780MX is a digital outdoor dual side-view detector with 4x dual sensors used for interior, perimeter and outdoor motion detection. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- Digital Outdoor Dual Side-View Detector with 4x Dual Sensors
- Family
- Paradox EVO
- Connection
- EVO bus or detector-specific connection
Specifications and planning notes
| Model | NV780MX |
|---|---|
| Product type | Digital Outdoor Dual Side-View Detector with 4x Dual Sensors |
| Product family | Paradox EVO |
| Category | Motion Detectors |
| Typical application | interior, perimeter and outdoor motion detection |
| Connection profile | EVO bus or detector-specific connection |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility review780MRC
The 780MRC is a nv780m series rain cover used for interior, perimeter and outdoor motion detection. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- NV780M Series Rain Cover
- Family
- Paradox EVO
- Connection
- EVO bus or detector-specific connection
Specifications and planning notes
| Model | 780MRC |
|---|---|
| Product type | NV780M Series Rain Cover |
| Product family | Paradox EVO |
| Category | Motion Detectors |
| Typical application | interior, perimeter and outdoor motion detection |
| Connection profile | EVO bus or detector-specific connection |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewSB35
The SB35 is a nv35m series wall bracket 90° used for interior, perimeter and outdoor motion detection. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- NV35M Series Wall Bracket 90°
- Family
- Paradox EVO
- Connection
- EVO bus or detector-specific connection
Specifications and planning notes
| Model | SB35 |
|---|---|
| Product type | NV35M Series Wall Bracket 90° |
| Product family | Paradox EVO |
| Category | Motion Detectors |
| Typical application | interior, perimeter and outdoor motion detection |
| Connection profile | EVO bus or detector-specific connection |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewNVX80
The NVX80 is a high end motion detector with anti-mask and seetrue technology for indoor / outdoor use used for interior, perimeter and outdoor motion detection. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- High End Motion Detector with Anti-Mask and SeeTrue Technology for Indoor / Outdoor Use
- Family
- Paradox EVO
- Connection
- EVO bus or detector-specific connection
Specifications and planning notes
| Model | NVX80 |
|---|---|
| Product type | High End Motion Detector with Anti-Mask and SeeTrue Technology for Indoor / Outdoor Use |
| Product family | Paradox EVO |
| Category | Motion Detectors |
| Typical application | interior, perimeter and outdoor motion detection |
| Connection profile | EVO bus or detector-specific connection |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewDM50
The DM50 is a dual element motion detector module used for interior, perimeter and outdoor motion detection. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- Dual Element Motion Detector Module
- Family
- Paradox EVO
- Connection
- EVO bus or detector-specific connection
Specifications and planning notes
| Model | DM50 |
|---|---|
| Product type | Dual Element Motion Detector Module |
| Product family | Paradox EVO |
| Category | Motion Detectors |
| Typical application | interior, perimeter and outdoor motion detection |
| Connection profile | EVO bus or detector-specific connection |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewDM60
The DM60 is a quad element motion detector module used for interior, perimeter and outdoor motion detection. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- Quad Element Motion Detector Module
- Family
- Paradox EVO
- Connection
- EVO bus or detector-specific connection
Specifications and planning notes
| Model | DM60 |
|---|---|
| Product type | Quad Element Motion Detector Module |
| Product family | Paradox EVO |
| Category | Motion Detectors |
| Typical application | interior, perimeter and outdoor motion detection |
| Connection profile | EVO bus or detector-specific connection |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewDM70
The DM70 is a high-security motion detector module with pet immunity used for interior, perimeter and outdoor motion detection. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- High-Security Motion Detector Module with Pet Immunity
- Family
- Paradox EVO
- Connection
- EVO bus or detector-specific connection
Specifications and planning notes
| Model | DM70 |
|---|---|
| Product type | High-Security Motion Detector Module with Pet Immunity |
| Product family | Paradox EVO |
| Category | Motion Detectors |
| Typical application | interior, perimeter and outdoor motion detection |
| Connection profile | EVO bus or detector-specific connection |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewSB85
The SB85 is a heavy duty outdoor swivel bracket used for interior, perimeter and outdoor motion detection. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- Heavy duty Outdoor Swivel Bracket
- Family
- Paradox EVO
- Connection
- EVO bus or detector-specific connection
Specifications and planning notes
| Model | SB85 |
|---|---|
| Product type | Heavy duty Outdoor Swivel Bracket |
| Product family | Paradox EVO |
| Category | Motion Detectors |
| Typical application | interior, perimeter and outdoor motion detection |
| Connection profile | EVO bus or detector-specific connection |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewDG85 Series
The DG85 Series is a outdoor high-security motion detector used for interior, perimeter and outdoor motion detection. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- Outdoor high-security motion detector
- Family
- Paradox EVO
- Connection
- EVO bus or detector-specific connection
Specifications and planning notes
| Model | DG85 Series |
|---|---|
| Product type | Outdoor high-security motion detector |
| Product family | Paradox EVO |
| Category | Motion Detectors |
| Typical application | interior, perimeter and outdoor motion detection |
| Connection profile | EVO bus or detector-specific connection |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewDG467
The DG467 is a 360° ceiling mounted digital motion detector used for interior, perimeter and outdoor motion detection. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- 360° Ceiling Mounted Digital Motion Detector
- Family
- Paradox EVO
- Connection
- EVO bus or detector-specific connection
Specifications and planning notes
| Model | DG467 |
|---|---|
| Product type | 360° Ceiling Mounted Digital Motion Detector |
| Product family | Paradox EVO |
| Category | Motion Detectors |
| Typical application | interior, perimeter and outdoor motion detection |
| Connection profile | EVO bus or detector-specific connection |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewDG457
The DG457 is a glassbreak bus detector used for interior, perimeter and outdoor motion detection. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- Glassbreak Bus Detector
- Family
- Paradox EVO
- Connection
- EVO bus or detector-specific connection
Specifications and planning notes
| Model | DG457 |
|---|---|
| Product type | Glassbreak Bus Detector |
| Product family | Paradox EVO |
| Category | Motion Detectors |
| Typical application | interior, perimeter and outdoor motion detection |
| Connection profile | EVO bus or detector-specific connection |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewZone Expansion Modules
ZX82
The ZX82 is a 8-zone expansion module used for expanding zone capacity and connecting field devices. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- 8-Zone Expansion Module
- Family
- Paradox EVO
- Connection
- EVO bus; RTX3 adds compatible wireless support
Specifications and planning notes
| Model | ZX82 |
|---|---|
| Product type | 8-Zone Expansion Module |
| Product family | Paradox EVO |
| Category | Zone Expansion Modules |
| Typical application | expanding zone capacity and connecting field devices |
| Connection profile | EVO bus; RTX3 adds compatible wireless support |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewZC1
The ZC1 is a door contact module used for expanding zone capacity and connecting field devices. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- Door Contact Module
- Family
- Paradox EVO
- Connection
- EVO bus; RTX3 adds compatible wireless support
Specifications and planning notes
| Model | ZC1 |
|---|---|
| Product type | Door Contact Module |
| Product family | Paradox EVO |
| Category | Zone Expansion Modules |
| Typical application | expanding zone capacity and connecting field devices |
| Connection profile | EVO bus; RTX3 adds compatible wireless support |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewZX1
The ZX1 is a 1-zone expansion module used for expanding zone capacity and connecting field devices. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- 1-Zone Expansion Module
- Family
- Paradox EVO
- Connection
- EVO bus; RTX3 adds compatible wireless support
Specifications and planning notes
| Model | ZX1 |
|---|---|
| Product type | 1-Zone Expansion Module |
| Product family | Paradox EVO |
| Category | Zone Expansion Modules |
| Typical application | expanding zone capacity and connecting field devices |
| Connection profile | EVO bus; RTX3 adds compatible wireless support |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewZX8
The ZX8 is a 8-zone expansion module used for expanding zone capacity and connecting field devices. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- 8-Zone Expansion Module
- Family
- Paradox EVO
- Connection
- EVO bus; RTX3 adds compatible wireless support
Specifications and planning notes
| Model | ZX8 |
|---|---|
| Product type | 8-Zone Expansion Module |
| Product family | Paradox EVO |
| Category | Zone Expansion Modules |
| Typical application | expanding zone capacity and connecting field devices |
| Connection profile | EVO bus; RTX3 adds compatible wireless support |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewRTX3
The RTX3 is a wireless expansion module used for expanding zone capacity and connecting field devices. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- Wireless Expansion Module
- Family
- Paradox EVO
- Connection
- EVO bus; RTX3 adds compatible wireless support
Specifications and planning notes
| Model | RTX3 |
|---|---|
| Product type | Wireless Expansion Module |
| Product family | Paradox EVO |
| Category | Zone Expansion Modules |
| Typical application | expanding zone capacity and connecting field devices |
| Connection profile | EVO bus; RTX3 adds compatible wireless support |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewAccess Control Modules
ACM12
The ACM12 is a 4-wire access control module used for controlled doors, card access and security integration. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- 4-Wire Access Control Module
- Family
- Paradox EVO
- Connection
- EVO access-control architecture and supported credentials
Specifications and planning notes
| Model | ACM12 |
|---|---|
| Product type | 4-Wire Access Control Module |
| Product family | Paradox EVO |
| Category | Access Control Modules |
| Typical application | controlled doors, card access and security integration |
| Connection profile | EVO access-control architecture and supported credentials |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewR915
The R915 is a 4-wire sealed indoor/outdoor proximity reader and keypad used for controlled doors, card access and security integration. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- 4-Wire Sealed Indoor/Outdoor Proximity Reader and Keypad
- Family
- Paradox EVO
- Connection
- EVO access-control architecture and supported credentials
Specifications and planning notes
| Model | R915 |
|---|---|
| Product type | 4-Wire Sealed Indoor/Outdoor Proximity Reader and Keypad |
| Product family | Paradox EVO |
| Category | Access Control Modules |
| Typical application | controlled doors, card access and security integration |
| Connection profile | EVO access-control architecture and supported credentials |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewR910
The R910 is a 4-wire indoor/outdoor proximity reader used for controlled doors, card access and security integration. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- 4-Wire Indoor/Outdoor Proximity Reader
- Family
- Paradox EVO
- Connection
- EVO access-control architecture and supported credentials
Specifications and planning notes
| Model | R910 |
|---|---|
| Product type | 4-Wire Indoor/Outdoor Proximity Reader |
| Product family | Paradox EVO |
| Category | Access Control Modules |
| Typical application | controlled doors, card access and security integration |
| Connection profile | EVO access-control architecture and supported credentials |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewC702
The C702 is a standard proximity card (clamshell) used for controlled doors, card access and security integration. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- Standard Proximity Card (Clamshell)
- Family
- Paradox EVO
- Connection
- EVO access-control architecture and supported credentials
Specifications and planning notes
| Model | C702 |
|---|---|
| Product type | Standard Proximity Card (Clamshell) |
| Product family | Paradox EVO |
| Category | Access Control Modules |
| Typical application | controlled doors, card access and security integration |
| Connection profile | EVO access-control architecture and supported credentials |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewC704
The C704 is a blue proximity key tag used for controlled doors, card access and security integration. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- Blue Proximity Key Tag
- Family
- Paradox EVO
- Connection
- EVO access-control architecture and supported credentials
Specifications and planning notes
| Model | C704 |
|---|---|
| Product type | Blue Proximity Key Tag |
| Product family | Paradox EVO |
| Category | Access Control Modules |
| Typical application | controlled doors, card access and security integration |
| Connection profile | EVO access-control architecture and supported credentials |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewC705
The C705 is a 4 color proximity cards used for controlled doors, card access and security integration. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- 4 Color Proximity Cards
- Family
- Paradox EVO
- Connection
- EVO access-control architecture and supported credentials
Specifications and planning notes
| Model | C705 |
|---|---|
| Product type | 4 Color Proximity Cards |
| Product family | Paradox EVO |
| Category | Access Control Modules |
| Typical application | controlled doors, card access and security integration |
| Connection profile | EVO access-control architecture and supported credentials |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewC706
The C706 is a iso proximity card used for controlled doors, card access and security integration. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- ISO Proximity Card
- Family
- Paradox EVO
- Connection
- EVO access-control architecture and supported credentials
Specifications and planning notes
| Model | C706 |
|---|---|
| Product type | ISO Proximity Card |
| Product family | Paradox EVO |
| Category | Access Control Modules |
| Typical application | controlled doors, card access and security integration |
| Connection profile | EVO access-control architecture and supported credentials |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewRAC1
The RAC1 is a remote control with integrated access card used for controlled doors, card access and security integration. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- Remote Control with Integrated Access Card
- Family
- Paradox EVO
- Connection
- EVO access-control architecture and supported credentials
Specifications and planning notes
| Model | RAC1 |
|---|---|
| Product type | Remote Control with Integrated Access Card |
| Product family | Paradox EVO |
| Category | Access Control Modules |
| Typical application | controlled doors, card access and security integration |
| Connection profile | EVO access-control architecture and supported credentials |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewSpecial Modules
PS45
The PS45 is a 75w 100-240 vac or 13.8 vdc battery to 15 vdc standalone or supervised backup power supply used for power distribution, integration and specialist system interfaces. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- 75W 100-240 Vac or 13.8 Vdc Battery to 15 Vdc Standalone or Supervised Backup Power Supply
- Family
- Paradox EVO
- Connection
- EVO bus or documented serial interface
Specifications and planning notes
| Model | PS45 |
|---|---|
| Product type | 75W 100-240 Vac or 13.8 Vdc Battery to 15 Vdc Standalone or Supervised Backup Power Supply |
| Product family | Paradox EVO |
| Category | Special Modules |
| Typical application | power distribution, integration and specialist system interfaces |
| Connection profile | EVO bus or documented serial interface |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewPS25
The PS25 is a 2.8a supervised power supply used for power distribution, integration and specialist system interfaces. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- 2.8A Supervised Power Supply
- Family
- Paradox EVO
- Connection
- EVO bus or documented serial interface
Specifications and planning notes
| Model | PS25 |
|---|---|
| Product type | 2.8A Supervised Power Supply |
| Product family | Paradox EVO |
| Category | Special Modules |
| Typical application | power distribution, integration and specialist system interfaces |
| Connection profile | EVO bus or documented serial interface |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewPS817
The PS817 is a switching power supply used for power distribution, integration and specialist system interfaces. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- Switching Power Supply
- Family
- Paradox EVO
- Connection
- EVO bus or documented serial interface
Specifications and planning notes
| Model | PS817 |
|---|---|
| Product type | Switching Power Supply |
| Product family | Paradox EVO |
| Category | Special Modules |
| Typical application | power distribution, integration and specialist system interfaces |
| Connection profile | EVO bus or documented serial interface |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewPRT3
The PRT3 is a integration module used for power distribution, integration and specialist system interfaces. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- Integration Module
- Family
- Paradox EVO
- Connection
- EVO bus or documented serial interface
Specifications and planning notes
| Model | PRT3 |
|---|---|
| Product type | Integration Module |
| Product family | Paradox EVO |
| Category | Special Modules |
| Typical application | power distribution, integration and specialist system interfaces |
| Connection profile | EVO bus or documented serial interface |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewBUS2SER
The BUS2SER is a evo rs232 interface used for power distribution, integration and specialist system interfaces. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- EVO RS232 Interface
- Family
- Paradox EVO
- Connection
- EVO bus or documented serial interface
Specifications and planning notes
| Model | BUS2SER |
|---|---|
| Product type | EVO RS232 Interface |
| Product family | Paradox EVO |
| Category | Special Modules |
| Typical application | power distribution, integration and specialist system interfaces |
| Connection profile | EVO bus or documented serial interface |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewAccessories
307USB
The 307USB is a direct connect interface used for commissioning, service and bus organization. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- Direct Connect Interface
- Family
- Paradox EVO
- Connection
- Installer/service accessory
Specifications and planning notes
| Model | 307USB |
|---|---|
| Product type | Direct Connect Interface |
| Product family | Paradox EVO |
| Category | Accessories |
| Typical application | commissioning, service and bus organization |
| Connection profile | Installer/service accessory |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewHUB2
The HUB2 is a hub and bus isolator used for commissioning, service and bus organization. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- Hub and bus isolator
- Family
- Paradox EVO
- Connection
- Installer/service accessory
Specifications and planning notes
| Model | HUB2 |
|---|---|
| Product type | Hub and bus isolator |
| Product family | Paradox EVO |
| Category | Accessories |
| Typical application | commissioning, service and bus organization |
| Connection profile | Installer/service accessory |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewCV4USB
The CV4USB is a rs-485/rs-232 converter kit used for commissioning, service and bus organization. It is planned within the EVO architecture and matched to the panel, bus capacity and firmware.
- Product type
- RS-485/RS-232 Converter Kit
- Family
- Paradox EVO
- Connection
- Installer/service accessory
Specifications and planning notes
| Model | CV4USB |
|---|---|
| Product type | RS-485/RS-232 Converter Kit |
| Product family | Paradox EVO |
| Category | Accessories |
| Typical application | commissioning, service and bus organization |
| Connection profile | Installer/service accessory |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewProduct Family
Magellan
Control Panels & Keypads
MG5050+
The MG5050+ is a magellan 32-zone wireless transceiver control panel used for system control, arming, status and user operation. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- Magellan 32-Zone Wireless Transceiver Control Panel
- Family
- Paradox Magellan
- Connection
- Magellan wireless and model-specific hardwired keypad connections
Specifications and planning notes
| Model | MG5050+ |
|---|---|
| Product type | Magellan 32-Zone Wireless Transceiver Control Panel |
| Product family | Paradox Magellan |
| Category | Control Panels & Keypads |
| Typical application | system control, arming, status and user operation |
| Connection profile | Magellan wireless and model-specific hardwired keypad connections |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewK38
The K38 is a 32-zone wireless fixed lcd keypad used for system control, arming, status and user operation. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- 32-Zone Wireless Fixed LCD Keypad
- Family
- Paradox Magellan
- Connection
- Magellan wireless and model-specific hardwired keypad connections
Specifications and planning notes
| Model | K38 |
|---|---|
| Product type | 32-Zone Wireless Fixed LCD Keypad |
| Product family | Paradox Magellan |
| Category | Control Panels & Keypads |
| Typical application | system control, arming, status and user operation |
| Connection profile | Magellan wireless and model-specific hardwired keypad connections |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewTM70 Touch
The TM70 Touch is a intuitive touchscreen used for system control, arming, status and user operation. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- Intuitive Touchscreen
- Family
- Paradox Magellan
- Connection
- Magellan wireless and model-specific hardwired keypad connections
Specifications and planning notes
| Model | TM70 Touch |
|---|---|
| Product type | Intuitive Touchscreen |
| Product family | Paradox Magellan |
| Category | Control Panels & Keypads |
| Typical application | system control, arming, status and user operation |
| Connection profile | Magellan wireless and model-specific hardwired keypad connections |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewTM70WB
The TM70WB is a tm70 in-wall bracket used for system control, arming, status and user operation. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- TM70 In-Wall Bracket
- Family
- Paradox Magellan
- Connection
- Magellan wireless and model-specific hardwired keypad connections
Specifications and planning notes
| Model | TM70WB |
|---|---|
| Product type | TM70 In-Wall Bracket |
| Product family | Paradox Magellan |
| Category | Control Panels & Keypads |
| Typical application | system control, arming, status and user operation |
| Connection profile | Magellan wireless and model-specific hardwired keypad connections |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewTM50 Touch
The TM50 Touch is a intuitive touchscreen used for system control, arming, status and user operation. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- Intuitive Touchscreen
- Family
- Paradox Magellan
- Connection
- Magellan wireless and model-specific hardwired keypad connections
Specifications and planning notes
| Model | TM50 Touch |
|---|---|
| Product type | Intuitive Touchscreen |
| Product family | Paradox Magellan |
| Category | Control Panels & Keypads |
| Typical application | system control, arming, status and user operation |
| Connection profile | Magellan wireless and model-specific hardwired keypad connections |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewTM50WB
The TM50WB is a tm50 in-wall bracket used for system control, arming, status and user operation. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- TM50 In-Wall Bracket
- Family
- Paradox Magellan
- Connection
- Magellan wireless and model-specific hardwired keypad connections
Specifications and planning notes
| Model | TM50WB |
|---|---|
| Product type | TM50 In-Wall Bracket |
| Product family | Paradox Magellan |
| Category | Control Panels & Keypads |
| Typical application | system control, arming, status and user operation |
| Connection profile | Magellan wireless and model-specific hardwired keypad connections |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewK32LCD+
The K32LCD+ is a 32-character hardwired lcd keypad module used for system control, arming, status and user operation. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- 32-Character Hardwired LCD Keypad Module
- Family
- Paradox Magellan
- Connection
- Magellan wireless and model-specific hardwired keypad connections
Specifications and planning notes
| Model | K32LCD+ |
|---|---|
| Product type | 32-Character Hardwired LCD Keypad Module |
| Product family | Paradox Magellan |
| Category | Control Panels & Keypads |
| Typical application | system control, arming, status and user operation |
| Connection profile | Magellan wireless and model-specific hardwired keypad connections |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewK32+
The K32+ is a 32-zone hardwired led keypad module used for system control, arming, status and user operation. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- 32-Zone Hardwired LED Keypad Module
- Family
- Paradox Magellan
- Connection
- Magellan wireless and model-specific hardwired keypad connections
Specifications and planning notes
| Model | K32+ |
|---|---|
| Product type | 32-Zone Hardwired LED Keypad Module |
| Product family | Paradox Magellan |
| Category | Control Panels & Keypads |
| Typical application | system control, arming, status and user operation |
| Connection profile | Magellan wireless and model-specific hardwired keypad connections |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewPA6
The PA6 is a 6vdc power adapter plug used for system control, arming, status and user operation. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- 6Vdc Power Adapter Plug
- Family
- Paradox Magellan
- Connection
- Magellan wireless and model-specific hardwired keypad connections
Specifications and planning notes
| Model | PA6 |
|---|---|
| Product type | 6Vdc Power Adapter Plug |
| Product family | Paradox Magellan |
| Category | Control Panels & Keypads |
| Typical application | system control, arming, status and user operation |
| Connection profile | Magellan wireless and model-specific hardwired keypad connections |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewK35
The K35 is a 32-zone hardwired fixed lcd keypad module used for system control, arming, status and user operation. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- 32-Zone Hardwired Fixed LCD Keypad Module
- Family
- Paradox Magellan
- Connection
- Magellan wireless and model-specific hardwired keypad connections
Specifications and planning notes
| Model | K35 |
|---|---|
| Product type | 32-Zone Hardwired Fixed LCD Keypad Module |
| Product family | Paradox Magellan |
| Category | Control Panels & Keypads |
| Typical application | system control, arming, status and user operation |
| Connection profile | Magellan wireless and model-specific hardwired keypad connections |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewK636
The K636 is a 10-zone hardwired led keypad used for system control, arming, status and user operation. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- 10-Zone Hardwired LED Keypad
- Family
- Paradox Magellan
- Connection
- Magellan wireless and model-specific hardwired keypad connections
Specifications and planning notes
| Model | K636 |
|---|---|
| Product type | 10-Zone Hardwired LED Keypad |
| Product family | Paradox Magellan |
| Category | Control Panels & Keypads |
| Typical application | system control, arming, status and user operation |
| Connection profile | Magellan wireless and model-specific hardwired keypad connections |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewK10V
The K10V is a 10-zone hardwired led keypad module (vertical) used for system control, arming, status and user operation. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- 10-Zone Hardwired LED Keypad Module (Vertical)
- Family
- Paradox Magellan
- Connection
- Magellan wireless and model-specific hardwired keypad connections
Specifications and planning notes
| Model | K10V |
|---|---|
| Product type | 10-Zone Hardwired LED Keypad Module (Vertical) |
| Product family | Paradox Magellan |
| Category | Control Panels & Keypads |
| Typical application | system control, arming, status and user operation |
| Connection profile | Magellan wireless and model-specific hardwired keypad connections |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewK10H
The K10H is a 10-zone hardwired led keypad module (horizontal) used for system control, arming, status and user operation. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- 10-Zone Hardwired LED Keypad Module (Horizontal)
- Family
- Paradox Magellan
- Connection
- Magellan wireless and model-specific hardwired keypad connections
Specifications and planning notes
| Model | K10H |
|---|---|
| Product type | 10-Zone Hardwired LED Keypad Module (Horizontal) |
| Product family | Paradox Magellan |
| Category | Control Panels & Keypads |
| Typical application | system control, arming, status and user operation |
| Connection profile | Magellan wireless and model-specific hardwired keypad connections |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewRemote Controls
REM25
The REM25 is a two-way wireless remote control used for arming, disarming, panic and programmable user actions. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- Two-way Wireless Remote Control
- Family
- Paradox Magellan
- Connection
- Compatible Magellan wireless receiver or panel
Specifications and planning notes
| Model | REM25 |
|---|---|
| Product type | Two-way Wireless Remote Control |
| Product family | Paradox Magellan |
| Category | Remote Controls |
| Typical application | arming, disarming, panic and programmable user actions |
| Connection profile | Compatible Magellan wireless receiver or panel |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewREM101
The REM101 is a emergency/panic remote control used for arming, disarming, panic and programmable user actions. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- Emergency/Panic Remote Control
- Family
- Paradox Magellan
- Connection
- Compatible Magellan wireless receiver or panel
Specifications and planning notes
| Model | REM101 |
|---|---|
| Product type | Emergency/Panic Remote Control |
| Product family | Paradox Magellan |
| Category | Remote Controls |
| Typical application | arming, disarming, panic and programmable user actions |
| Connection profile | Compatible Magellan wireless receiver or panel |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewBC101
The BC101 is a belt clip used for arming, disarming, panic and programmable user actions. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- Belt Clip
- Family
- Paradox Magellan
- Connection
- Compatible Magellan wireless receiver or panel
Specifications and planning notes
| Model | BC101 |
|---|---|
| Product type | Belt Clip |
| Product family | Paradox Magellan |
| Category | Remote Controls |
| Typical application | arming, disarming, panic and programmable user actions |
| Connection profile | Compatible Magellan wireless receiver or panel |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewB101
The B101 is a bracelet used for arming, disarming, panic and programmable user actions. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- Bracelet
- Family
- Paradox Magellan
- Connection
- Compatible Magellan wireless receiver or panel
Specifications and planning notes
| Model | B101 |
|---|---|
| Product type | Bracelet |
| Product family | Paradox Magellan |
| Category | Remote Controls |
| Typical application | arming, disarming, panic and programmable user actions |
| Connection profile | Compatible Magellan wireless receiver or panel |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewWB101
The WB101 is a wall bracket used for arming, disarming, panic and programmable user actions. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- Wall Bracket
- Family
- Paradox Magellan
- Connection
- Compatible Magellan wireless receiver or panel
Specifications and planning notes
| Model | WB101 |
|---|---|
| Product type | Wall Bracket |
| Product family | Paradox Magellan |
| Category | Remote Controls |
| Typical application | arming, disarming, panic and programmable user actions |
| Connection profile | Compatible Magellan wireless receiver or panel |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewREM2
The REM2 is a magellan 2-way remote control with backlit buttons used for arming, disarming, panic and programmable user actions. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- MAGELLAN 2-Way Remote Control with Backlit Buttons
- Family
- Paradox Magellan
- Connection
- Compatible Magellan wireless receiver or panel
Specifications and planning notes
| Model | REM2 |
|---|---|
| Product type | MAGELLAN 2-Way Remote Control with Backlit Buttons |
| Product family | Paradox Magellan |
| Category | Remote Controls |
| Typical application | arming, disarming, panic and programmable user actions |
| Connection profile | Compatible Magellan wireless receiver or panel |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewVC20
The VC20 is a visor clip for rem2 used for arming, disarming, panic and programmable user actions. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- Visor Clip for REM2
- Family
- Paradox Magellan
- Connection
- Compatible Magellan wireless receiver or panel
Specifications and planning notes
| Model | VC20 |
|---|---|
| Product type | Visor Clip for REM2 |
| Product family | Paradox Magellan |
| Category | Remote Controls |
| Typical application | arming, disarming, panic and programmable user actions |
| Connection profile | Compatible Magellan wireless receiver or panel |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewRAC1
The RAC1 is a remote control with integrated access card used for arming, disarming, panic and programmable user actions. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- Remote Control with Integrated Access Card
- Family
- Paradox Magellan
- Connection
- Compatible Magellan wireless receiver or panel
Specifications and planning notes
| Model | RAC1 |
|---|---|
| Product type | Remote Control with Integrated Access Card |
| Product family | Paradox Magellan |
| Category | Remote Controls |
| Typical application | arming, disarming, panic and programmable user actions |
| Connection profile | Compatible Magellan wireless receiver or panel |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewWireless Motion Detectors
NV37MR
The NV37MR is a wireless outdoor / indoor window and sliding door dual detector with anti-masking and pet immunity used for interior, window, perimeter and outdoor detection. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- Wireless Outdoor / Indoor Window and Sliding Door Dual Detector with Anti-Masking and Pet Immunity
- Family
- Paradox Magellan
- Connection
- Magellan 433/868 MHz wireless; regional version must match the panel
Specifications and planning notes
| Model | NV37MR |
|---|---|
| Product type | Wireless Outdoor / Indoor Window and Sliding Door Dual Detector with Anti-Masking and Pet Immunity |
| Product family | Paradox Magellan |
| Category | Wireless Motion Detectors |
| Typical application | interior, window, perimeter and outdoor detection |
| Connection profile | Magellan 433/868 MHz wireless; regional version must match the panel |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewNV780MR
The NV780MR is a digital outdoor dual side-view detector with 4x dual sensors used for interior, window, perimeter and outdoor detection. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- Digital Outdoor Dual Side-View Detector with 4x Dual Sensors
- Family
- Paradox Magellan
- Connection
- Magellan 433/868 MHz wireless; regional version must match the panel
Specifications and planning notes
| Model | NV780MR |
|---|---|
| Product type | Digital Outdoor Dual Side-View Detector with 4x Dual Sensors |
| Product family | Paradox Magellan |
| Category | Wireless Motion Detectors |
| Typical application | interior, window, perimeter and outdoor detection |
| Connection profile | Magellan 433/868 MHz wireless; regional version must match the panel |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility review780MRC
The 780MRC is a nv780m series rain cover used for interior, window, perimeter and outdoor detection. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- NV780M Series Rain Cover
- Family
- Paradox Magellan
- Connection
- Magellan 433/868 MHz wireless; regional version must match the panel
Specifications and planning notes
| Model | 780MRC |
|---|---|
| Product type | NV780M Series Rain Cover |
| Product family | Paradox Magellan |
| Category | Wireless Motion Detectors |
| Typical application | interior, window, perimeter and outdoor detection |
| Connection profile | Magellan 433/868 MHz wireless; regional version must match the panel |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewSB35
The SB35 is a nv35m series wall bracket 90° used for interior, window, perimeter and outdoor detection. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- NV35M Series Wall Bracket 90°
- Family
- Paradox Magellan
- Connection
- Magellan 433/868 MHz wireless; regional version must match the panel
Specifications and planning notes
| Model | SB35 |
|---|---|
| Product type | NV35M Series Wall Bracket 90° |
| Product family | Paradox Magellan |
| Category | Wireless Motion Detectors |
| Typical application | interior, window, perimeter and outdoor detection |
| Connection profile | Magellan 433/868 MHz wireless; regional version must match the panel |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewPMD2P
The PMD2P is a wireless pir motion detector with built-in pet immunity used for interior, window, perimeter and outdoor detection. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- Wireless PIR Motion Detector with Built-in Pet Immunity
- Family
- Paradox Magellan
- Connection
- Magellan 433/868 MHz wireless; regional version must match the panel
Specifications and planning notes
| Model | PMD2P |
|---|---|
| Product type | Wireless PIR Motion Detector with Built-in Pet Immunity |
| Product family | Paradox Magellan |
| Category | Wireless Motion Detectors |
| Typical application | interior, window, perimeter and outdoor detection |
| Connection profile | Magellan 433/868 MHz wireless; regional version must match the panel |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewPMD75N
The PMD75N is a digital dual-optic high-performance pir used for interior, window, perimeter and outdoor detection. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- Digital Dual-Optic High-Performance PIR
- Family
- Paradox Magellan
- Connection
- Magellan 433/868 MHz wireless; regional version must match the panel
Specifications and planning notes
| Model | PMD75N |
|---|---|
| Product type | Digital Dual-Optic High-Performance PIR |
| Product family | Paradox Magellan |
| Category | Wireless Motion Detectors |
| Typical application | interior, window, perimeter and outdoor detection |
| Connection profile | Magellan 433/868 MHz wireless; regional version must match the panel |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewPMD85 Series
The PMD85 Series is a outdoor digital dual-optic high-performance pir used for interior, window, perimeter and outdoor detection. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- Outdoor Digital Dual-Optic High-Performance PIR
- Family
- Paradox Magellan
- Connection
- Magellan 433/868 MHz wireless; regional version must match the panel
Specifications and planning notes
| Model | PMD85 Series |
|---|---|
| Product type | Outdoor Digital Dual-Optic High-Performance PIR |
| Product family | Paradox Magellan |
| Category | Wireless Motion Detectors |
| Typical application | interior, window, perimeter and outdoor detection |
| Connection profile | Magellan 433/868 MHz wireless; regional version must match the panel |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewSB85
The SB85 is a heavy duty outdoor swivel bracket used for interior, window, perimeter and outdoor detection. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- Heavy duty Outdoor Swivel Bracket
- Family
- Paradox Magellan
- Connection
- Magellan 433/868 MHz wireless; regional version must match the panel
Specifications and planning notes
| Model | SB85 |
|---|---|
| Product type | Heavy duty Outdoor Swivel Bracket |
| Product family | Paradox Magellan |
| Category | Wireless Motion Detectors |
| Typical application | interior, window, perimeter and outdoor detection |
| Connection profile | Magellan 433/868 MHz wireless; regional version must match the panel |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewWireless Sirens
SR230
The SR230 is a wireless outdoor siren with built-in strobe light used for audible and visible exterior alarm response. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- Wireless Outdoor Siren with Built-in Strobe Light
- Family
- Paradox Magellan
- Connection
- Compatible Magellan wireless panel or transceiver
Specifications and planning notes
| Model | SR230 |
|---|---|
| Product type | Wireless Outdoor Siren with Built-in Strobe Light |
| Product family | Paradox Magellan |
| Category | Wireless Sirens |
| Typical application | audible and visible exterior alarm response |
| Connection profile | Compatible Magellan wireless panel or transceiver |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewSR250
The SR250 is a wireless siren with built-in strobe used for audible and visible exterior alarm response. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- Wireless Siren with Built-in Strobe
- Family
- Paradox Magellan
- Connection
- Compatible Magellan wireless panel or transceiver
Specifications and planning notes
| Model | SR250 |
|---|---|
| Product type | Wireless Siren with Built-in Strobe |
| Product family | Paradox Magellan |
| Category | Wireless Sirens |
| Typical application | audible and visible exterior alarm response |
| Connection profile | Compatible Magellan wireless panel or transceiver |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewWireless Door Contacts
DCT6
The DCT6 is a wireless door contact used for opening detection on doors, windows and connected contacts. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- Wireless Door Contact
- Family
- Paradox Magellan
- Connection
- Magellan 433/868 MHz wireless; verify the Canadian model
Specifications and planning notes
| Model | DCT6 |
|---|---|
| Product type | Wireless Door Contact |
| Product family | Paradox Magellan |
| Category | Wireless Door Contacts |
| Typical application | opening detection on doors, windows and connected contacts |
| Connection profile | Magellan 433/868 MHz wireless; verify the Canadian model |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewDCT10
The DCT10 is a 2-zone long-range door contact used for opening detection on doors, windows and connected contacts. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- 2-Zone Long-Range Door Contact
- Family
- Paradox Magellan
- Connection
- Magellan 433/868 MHz wireless; verify the Canadian model
Specifications and planning notes
| Model | DCT10 |
|---|---|
| Product type | 2-Zone Long-Range Door Contact |
| Product family | Paradox Magellan |
| Category | Wireless Door Contacts |
| Typical application | opening detection on doors, windows and connected contacts |
| Connection profile | Magellan 433/868 MHz wireless; verify the Canadian model |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewDCTXP2
The DCTXP2 is a 2-zone wireless door contact used for opening detection on doors, windows and connected contacts. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- 2-Zone Wireless Door Contact
- Family
- Paradox Magellan
- Connection
- Magellan 433/868 MHz wireless; verify the Canadian model
Specifications and planning notes
| Model | DCTXP2 |
|---|---|
| Product type | 2-Zone Wireless Door Contact |
| Product family | Paradox Magellan |
| Category | Wireless Door Contacts |
| Typical application | opening detection on doors, windows and connected contacts |
| Connection profile | Magellan 433/868 MHz wireless; verify the Canadian model |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewWireless Accessories
G550
The G550 is a wireless glassbreak detector used for specialized wireless detection, coverage and output control. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- Wireless Glassbreak Detector
- Family
- Paradox Magellan
- Connection
- Magellan wireless or accessory-specific power connection
Specifications and planning notes
| Model | G550 |
|---|---|
| Product type | Wireless Glassbreak Detector |
| Product family | Paradox Magellan |
| Category | Wireless Accessories |
| Typical application | specialized wireless detection, coverage and output control |
| Connection profile | Magellan wireless or accessory-specific power connection |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility review5709C
The 5709C is a acoustic glass break sensor tester used for specialized wireless detection, coverage and output control. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- Acoustic Glass Break Sensor Tester
- Family
- Paradox Magellan
- Connection
- Magellan wireless or accessory-specific power connection
Specifications and planning notes
| Model | 5709C |
|---|---|
| Product type | Acoustic Glass Break Sensor Tester |
| Product family | Paradox Magellan |
| Category | Wireless Accessories |
| Typical application | specialized wireless detection, coverage and output control |
| Connection profile | Magellan wireless or accessory-specific power connection |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewRPT1+
The RPT1+ is a wireless repeater module used for specialized wireless detection, coverage and output control. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- Wireless Repeater Module
- Family
- Paradox Magellan
- Connection
- Magellan wireless or accessory-specific power connection
Specifications and planning notes
| Model | RPT1+ |
|---|---|
| Product type | Wireless Repeater Module |
| Product family | Paradox Magellan |
| Category | Wireless Accessories |
| Typical application | specialized wireless detection, coverage and output control |
| Connection profile | Magellan wireless or accessory-specific power connection |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility review2WPGM
The 2WPGM is a magellan 2-way wireless pgm used for specialized wireless detection, coverage and output control. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- MAGELLAN 2-Way Wireless PGM
- Family
- Paradox Magellan
- Connection
- Magellan wireless or accessory-specific power connection
Specifications and planning notes
| Model | 2WPGM |
|---|---|
| Product type | MAGELLAN 2-Way Wireless PGM |
| Product family | Paradox Magellan |
| Category | Wireless Accessories |
| Typical application | specialized wireless detection, coverage and output control |
| Connection profile | Magellan wireless or accessory-specific power connection |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewPA12
The PA12 is a 13.8 vdc power adapter plug used for specialized wireless detection, coverage and output control. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- 13.8 Vdc Power Adapter Plug
- Family
- Paradox Magellan
- Connection
- Magellan wireless or accessory-specific power connection
Specifications and planning notes
| Model | PA12 |
|---|---|
| Product type | 13.8 Vdc Power Adapter Plug |
| Product family | Paradox Magellan |
| Category | Wireless Accessories |
| Typical application | specialized wireless detection, coverage and output control |
| Connection profile | Magellan wireless or accessory-specific power connection |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewZone Expansion Modules
ZX22
The ZX22 is a magellan universal 2-zone transmitter used for adding supervised wired zones and reusing existing cabling. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- Magellan Universal 2-Zone Transmitter
- Family
- Paradox Magellan
- Connection
- Compatible panel bus or model-specific expansion connection
Specifications and planning notes
| Model | ZX22 |
|---|---|
| Product type | Magellan Universal 2-Zone Transmitter |
| Product family | Paradox Magellan |
| Category | Zone Expansion Modules |
| Typical application | adding supervised wired zones and reusing existing cabling |
| Connection profile | Compatible panel bus or model-specific expansion connection |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewZX82
The ZX82 is a 8-zone expansion module used for adding supervised wired zones and reusing existing cabling. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- 8-Zone Expansion Module
- Family
- Paradox Magellan
- Connection
- Compatible panel bus or model-specific expansion connection
Specifications and planning notes
| Model | ZX82 |
|---|---|
| Product type | 8-Zone Expansion Module |
| Product family | Paradox Magellan |
| Category | Zone Expansion Modules |
| Typical application | adding supervised wired zones and reusing existing cabling |
| Connection profile | Compatible panel bus or model-specific expansion connection |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewZX8SP
The ZX8SP is a 8-zone expansion module used for adding supervised wired zones and reusing existing cabling. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- 8-Zone Expansion Module
- Family
- Paradox Magellan
- Connection
- Compatible panel bus or model-specific expansion connection
Specifications and planning notes
| Model | ZX8SP |
|---|---|
| Product type | 8-Zone Expansion Module |
| Product family | Paradox Magellan |
| Category | Zone Expansion Modules |
| Typical application | adding supervised wired zones and reusing existing cabling |
| Connection profile | Compatible panel bus or model-specific expansion connection |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewZX8
The ZX8 is a 8-zone expansion module used for adding supervised wired zones and reusing existing cabling. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- 8-Zone Expansion Module
- Family
- Paradox Magellan
- Connection
- Compatible panel bus or model-specific expansion connection
Specifications and planning notes
| Model | ZX8 |
|---|---|
| Product type | 8-Zone Expansion Module |
| Product family | Paradox Magellan |
| Category | Zone Expansion Modules |
| Typical application | adding supervised wired zones and reusing existing cabling |
| Connection profile | Compatible panel bus or model-specific expansion connection |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewPGM Expansion Modules
PGM82
The PGM82 is a 8-pgm expansion module used for adding programmable control outputs. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- 8-PGM Expansion Module
- Family
- Paradox Magellan
- Connection
- Compatible panel bus
Specifications and planning notes
| Model | PGM82 |
|---|---|
| Product type | 8-PGM Expansion Module |
| Product family | Paradox Magellan |
| Category | PGM Expansion Modules |
| Typical application | adding programmable control outputs |
| Connection profile | Compatible panel bus |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewPGM4
The PGM4 is a 4-pgm expansion module used for adding programmable control outputs. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- 4-PGM Expansion Module
- Family
- Paradox Magellan
- Connection
- Compatible panel bus
Specifications and planning notes
| Model | PGM4 |
|---|---|
| Product type | 4-PGM Expansion Module |
| Product family | Paradox Magellan |
| Category | PGM Expansion Modules |
| Typical application | adding programmable control outputs |
| Connection profile | Compatible panel bus |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewSpecial Modules
PS45
The PS45 is a 75w 100-240 vac or 13.8 vdc battery to 15 vdc standalone or supervised backup power supply used for supplementary supervised power and battery support. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- 75W 100-240 Vac or 13.8 Vdc Battery to 15 Vdc Standalone or Supervised Backup Power Supply
- Family
- Paradox Magellan
- Connection
- Compatible panel bus and documented power supply
Specifications and planning notes
| Model | PS45 |
|---|---|
| Product type | 75W 100-240 Vac or 13.8 Vdc Battery to 15 Vdc Standalone or Supervised Backup Power Supply |
| Product family | Paradox Magellan |
| Category | Special Modules |
| Typical application | supplementary supervised power and battery support |
| Connection profile | Compatible panel bus and documented power supply |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewPS25
The PS25 is a 2.8a supervised power supply used for supplementary supervised power and battery support. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- 2.8A Supervised Power Supply
- Family
- Paradox Magellan
- Connection
- Compatible panel bus and documented power supply
Specifications and planning notes
| Model | PS25 |
|---|---|
| Product type | 2.8A Supervised Power Supply |
| Product family | Paradox Magellan |
| Category | Special Modules |
| Typical application | supplementary supervised power and battery support |
| Connection profile | Compatible panel bus and documented power supply |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewAccessories
307USB
The 307USB is a direct connect interface used for commissioning, service and bus organization. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- Direct Connect Interface
- Family
- Paradox Magellan
- Connection
- Installer/service accessory
Specifications and planning notes
| Model | 307USB |
|---|---|
| Product type | Direct Connect Interface |
| Product family | Paradox Magellan |
| Category | Accessories |
| Typical application | commissioning, service and bus organization |
| Connection profile | Installer/service accessory |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewHUB2
The HUB2 is a hub and bus isolator used for commissioning, service and bus organization. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- Hub and Bus Isolator
- Family
- Paradox Magellan
- Connection
- Installer/service accessory
Specifications and planning notes
| Model | HUB2 |
|---|---|
| Product type | Hub and Bus Isolator |
| Product family | Paradox Magellan |
| Category | Accessories |
| Typical application | commissioning, service and bus organization |
| Connection profile | Installer/service accessory |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewCV4USB
The CV4USB is a rs-485/rs-232 converter kit used for commissioning, service and bus organization. Its panel compatibility, radio version and Canadian availability are verified before installation.
- Product type
- RS-485/RS-232 Converter Kit
- Family
- Paradox Magellan
- Connection
- Installer/service accessory
Specifications and planning notes
| Model | CV4USB |
|---|---|
| Product type | RS-485/RS-232 Converter Kit |
| Product family | Paradox Magellan |
| Category | Accessories |
| Typical application | commissioning, service and bus organization |
| Connection profile | Installer/service accessory |
| Planning note | MSSCO confirms panel, firmware, regional frequency, certification and supplier availability before specification. |
Technical review: Compatibility, availability, certifications, and the formal installation scope require MSSCO technical review before quotation.
Request an MSSCO compatibility reviewMSSCO Process
From platform choice to a reviewed and tested system
- 01
Identify the family
Confirm the panel, region, firmware, devices, modules, communications, and project objective.
- 02
Verify each branch
Check capacity, bus or wireless path, power, programming, subscriptions, availability, and dependencies.
- 03
Install and document
Deliver the approved scope, test all zones and workflows, document, and hand over operation.
Frequently Asked Questions
Useful answers before technical review
Can M, EVO, and Magellan products be mixed freely?
No. Similar roles do not establish compatibility. Platform, bus or wireless path, regional frequency, firmware, capacity, and exact model must be verified.
Are all catalogue specifications current production rules?
No. Existing published data is preserved for staging. Manufacturer evidence, availability, regional model, and compatibility require audit before a specification governs quotations or orders.
Can MSSCO provide an instant Paradox system price?
Formal pricing follows review of the panel, devices, quantities, wiring, communications, monitoring, subscriptions, availability, and installation conditions.
Next Step
Start with the Paradox platform and the required system outcome
Tell us whether the project uses M System, EVO, Magellan, or an unknown existing panel. MSSCO will define the verification path.
